Eco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty
Eco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty
Eco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty
Eco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty
Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Material :
Monocrystalline Silicon
Size :
1960*992*50mm
Front Cover :
3.2mm High transmission
Application :
Industry
Color :
White, Black
Warranty :
25 years
Cell Grade :
A-Grade
Fram :
Aluminum Alloy
Description

High Efficiency Monocrystalline Solar Panel Solar Energy Systems Uses 100w Mono Solar Cells, Solar Panels

Product Description

DDP Rotterdam 260W TUV CE Mcs Cec Polycrystalline Solar Module(ODA260-30-P)


Features:


High conversion efficiency
Low power tolerance of 0~+3%
Low degradation under light exposure
Can withstand high wind-pressure, snow load and extreme temperature
Passing IEC 61215 5400Pa mechanical load test

Quality and Safety:


10-year warranty on product materials and processing technology
Power output warranty: 10 years: 90%, 25 years: 80%
ISO 9001: 2008(Quality Management System) certified factory
IEC61215, IEC61730, MCS CEC certified products
TUV, CE conformity

Applications


On-grid residential roof-tops
On-grid commercial/industrial roof-tops
Solar power plants
Off-grid system
Other on-grid applications

Specifications


Model Type		 ODA260-30-P
Peak Power(Pmax) 260.00
Maximum Power Voltage(Vmp) 31.70
Maximum Power Current(Imp) 8.21
Open Circuit Voltage(Voc) 38.04
Short Circuit Current(Isc) 9.03
Cells Efficiency() 18.21
Module Efficiency() 16.01
Maximum System Voltage(V) 1000
Maximum Series Fuse Rating(A) 15
Power Tolerance 0~+3
Pmax Temperature Coefficients(W/ºC) -0.450
Voc Temperature Coefficients(V/ºC) -0.350
Isc Temperature Coefficients(A/ºC) +0.040
NOCT Nominal Operating Cell Temperature(ºC) 47±2
Operating and Storage Temperature(ºC) -40~+85
Standard Test Condition(STC) 1000W/; AM 1.5;25+/-2ºC



There are numerous factors you should first consider before you choose to buy solar panels and some of these factors are listed below:
1, Firstly you should always research whether or not your desired location for the installation of solar panels has adequate levels of sunshine to make your investment worthwhile.
2, You should decide on a sensible budget for your project before you buy your solar panels.
3, Determine what capacity of electricity you require and if your selected budget can accommodate this.
4, Who will install the solar panels that you buy? Do you require the additional services of an electrician or solar energy installer?
5, Where will the solar panels you buy be fixed to your home? Is your home capable of supporting a solar energy system?


Eco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty

High efficiency poly solar cell with positive tolerance only
International quality management system with 100% panel power and EL test before shipment
Fire test, Ammonia corrosion test, Salt mist corrosion resistance approved
Nearest shipment port: ShanghaiEco Friendly Solar Pv Modules Anodized Aluminum Frame 25 Years Warranty
