High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation
High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation
Specifications
Brand Name :
Yingli/Jinko
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiation
Payment Terms :
T/T、L/C、West Union
Supply Ability :
5000000 Watt/Watts per Month
Delivery Time :
Shipped in 7 days after payment
Packaging Details :
In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ
Voltage :
120V/240V
Power Tolerance(W) :
-0-+5W
Junction Box :
IP65/IP67
Power tolerance :
0~+3%
Lifespan :
More than 25 years
Solar Panel :
Mono/Poly
Material :
Polycrystalline Silicon
Minimum Order :
10pcs
Description

High Efficiency Solar Panels For Homes , Aluminum Alloy Plated Oxidation Framworld.315Wp

Monocrystalline Solar Panel

Triple International Electrical Commission (IEC) test guarantees long-term reliability
Excellent anti-PID performance
Double electroluminescence (EL) tests guarantee fault-free modules
Lower contact resistance and optimized soldered connections as well as reduced grid breakage of cell conductor tracks through double-printing technology
100% automated production facilities using state-of-the-art plant technology

Moduel
KL-300W-M
 KL-305W-M
KL-310W-M
KL-320W-M
 KL-325-M
Rated Maximum Power at STC
300
305
310
320
325
Open Circuit Voltage(Voc/V)
45.20
45.35
45.45
45.82
46.48
Maximum Power Voltage(Vmp/V)
36.41
36.71
37.00
37.56
37.17
Short Circuit Current(Isc/A)
8.73
8.79
8.85
9.03
9.05
Maximum Power Current(Imp/A)
8.24
8.31
8.38
8.52
8.74
Module Efficiency(%)
15.48
15.73
15.99
16.51
16.77
Power Tolerance
-0~+3%
Standard Test Condition(STC)
Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5

PRODUCTS SPECIFICATION:

Quality and Safety

1. Rigorous quality control meets the highest international standards.

2. High-transmissivity low-iron tempered glass, strong aluminium frame.

3. Using UV-resistant silicon.

4. IS09001/14001/CE/TUV/UL

Warranties

1. 10 years limited product warranty

2. 15 years at 90% of the minimal rated power output

3. 25 years at 80% of the minimal rated power output

Technical date :

Characteristics Unit 315W
Maximum Power (Pmax) W 315
Power Tolerance W (0,+5)
Maximum Power Voltage (Vmp) V 36
Maximum Power Current (Imp) A 8.75
Open Circuit Voltage (Voc) V 43.2
Short Circuit Current (Isc) A 9.62
Module Efficiency (ηm) % 15.46
Dimension of module mm 1950*992*40mm
Pmax Temperature Coefficient %/C -0.42
Voc Temperature Coefficient %/C -0.3
Isc Temperature Coefficient %/C 0.05
Maximum System Voltage VDC 1000(TUV);600(UL)
Maximum Series Fuse Rating A 15
Operating Temperature C -40~ +85
NOCT C 45±2
STC:1000W/m2.AM1.5 and 25C cell temperature, NOCT : Nominal Operating Cell Temperature

Temperature Coefficient:

NOCT 45°C±2°C
Temperature coefficient of Isc 0.05%/°C
Temperature coefficient of Voc -0.33%/°C
Temperature coefficient of Pmax -0.44%/°C
Power Tolerance 0/+3%
Working temperature -40°C to 85°C

Qualification Test Parameters:

Temperature cycling range -40℃~85℃
Humidity freeze, damp heat 85%RH
Static load front and back (e.g. wind) 2400 pa (50psf)
Front loading (e.g. snow) 5400 pa (113psf)
Hailstone impact 25mm ( 1 inch) at 23 m/s (52mph)

Features of solar panel

Polycrystalline or Monocrystalline silicon is a material consisting of thin wafers that are cut from a silicon crystal which has grown in several directions. This advanced texturing process provides polycrystalline or moncrystalline solar panels with a higher power output than amorphous panels of the same dimensions, and makes them more cost and space-effective. These individual wafers are assembled into panels that are covered by durable, weatherproof tempered glass. Thanks to their efficiency and durability, these solar panels require virtually no maintenance once installed.

Solar panel is super energy saving and makes people life happy

Solar panel helps us to take full advantage of solar energy which is clean, inexhautible and pollution-free, and it converts sunlight into electric. In this way, we can help people in remote areas without mains supply and lack of electricity, and light up nights and bring people hope there.

High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation

High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation

Application:

1, On industry building, commerce building and public buildings.

2, on steel structure workshop.

3, on roof of the residential building.

4, On mobile booth.

5, on agriculture and livestock facilities.

6, on sunshine house.

7, on water surface.

8, on brrack and post.

9, on the ground.

10, on railroad.

11, on public road.

12, on container box.

High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation

Packing:

High Efficiency Silicon Solar Panels Anti PID Performance Easy Installation

Quality and Safety

1. Rigorous quality control meets the highest international standards.

2. High-transmissivity low-iron tempered glass, strong aluminium frame.

3. Using UV-resistant silicon.

4. IS09001/14001/CE/TUV/UL

Payment Term

T/T

 EXW

30% T/T in advance, paid the balance before shipment
FOB
CFR(C&F)

30% T/T in advance, paid the balance against copy of B/L
CIF
L/C L/C amount above 50,000 usd, we can accept L/C at sight
West Union

Amount lower than 5000usd
West Union
Delivery Time 7~10days after receiving payment for one container
