Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame
Specifications
Brand Name :
Topray
Model Number :
330W
Certification :
tuv
Place of Origin :
China
MOQ :
10000w
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
500000w per week
Delivery Time :
7-10working days
Packaging Details :
carton
Max. power :
330W
Color :
Dark Blue
Number of cells :
72pcs
Material :
Polycrystalline Silicon
Frame color :
White
Description

Poly Crystalline Grade B Single Glass In Dark Blue 5BB 330W Solar Panel White Frame

Technical Parameter

Maximum Power (Pmax) 330W
Open Circuit Voltage(Voc) 45.58V
Short Circuit Current(Isc) 9.35A
Maximum Power Voltage(Vmp) 37.21V
Maximum Power Current(Imp) 8.87V
Maximum System Voltage 1000VDC
Fuse Rating 15A
Module Fire Rating Class C
Snow load 5400pa

Poly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White FramePoly Crystalline Dark Blue 5BB 330W Grade B Solar Panels White Frame

FAQ

Q1: What is your MOQ?
A: We have no MOQ, 1pc sample order is also ok for us,but best Cost performance is by big quantity order.

Q2: Do you have any experience with big bidding projects?
A: Yes, we have rich experience on the big bidding projects, and have helped our customers win many such bidding projects. Our sale engineer are very familiar with the bidding procedure and can provide detailed information as required in time.

Q3: Do you accept OEM?
A: yes, we can do the OEM for you, and we are the OEM supplier of many famous brands from Europe, USA, Asia,Middle East and Africa etc.
