24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System
24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System
24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System
24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System
Specifications
Brand Name :
Yo Power Electrical
Model Number :
YQPV-HP24V/200A
Certification :
CE, ROHS, FCC
Place of Origin :
Anhui, China
MOQ :
1 units
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
500 units/month
Delivery Time :
Within 3 days for 1~10pcs order
Packaging Details :
Carton box with pearl sponge
Rated voltage :
24V
Max. charging current :
200A
Max. input solar power :
48KW
Display :
LCD+LED
Color :
White or customized
Warranty :
3 years
Description

24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System

This 24V 200A Solar charge controller is used for charging battery with solar power in off grid solar power system, it can work with 48KW PV arrays, with the PWM technology which satisfy the battery features to improve battery service time and improve battert activity 30% at least

1. Features

  • Industrial-grade chips and excellent EMC design to ensure stable performance
  • PWM technology improvides the charging efficiency and battery storage capability
  • Advanced battery activation technology increases battery lifetime 30% at least and improves the system performance
  • IGBT power module as electronic switch which can improve the stable performance
  • 3'' LCD screen and LED indicators show charging information and status
  • Parameters can be adjusted according to requirements of different battery
  • RS485/GPRS communication
  • RTC function
  • 3 years warranty, 5/10 years warranty for optional

2. Parameters

Model YQPV-HP48V/200A
Rated system voltage 24V
Max. charging current 200A
Max. input solar power 48KW
No. of input 4 groups
No-load loss <05.W
Equalize charging voltage 28.8V
Equalize charging time 120 minutes
Float charging voltage 27.6V
Equalize charging reovery voltage 26.4V
Over charge voltage 32V
Over charge recovery voltage 30V
Display language English
Display LCD+LED
Cooling method Fan+heat sink
Operatin temperature -25~75℃
Dimension 500*520*900mm
Weight 70kg
Warranty 3 years

24V 200A Solar Charge Controller For Charging Battery In 48KW Solar Power System
