DC To AC High Frequency Pure Sine Wave Inverter 500W Intelligent IC Control
DC To AC High Frequency Pure Sine Wave Inverter 500W Intelligent IC Control
DC To AC High Frequency Pure Sine Wave Inverter 500W Intelligent IC Control
DC To AC High Frequency Pure Sine Wave Inverter 500W Intelligent IC Control
Specifications
Brand Name :
Yo Power Electrical
Model Number :
YQHI-500W
Certification :
CE, ROHS, FCC
Place of Origin :
Anhui, China
MOQ :
10 units
Price :
Negotiable
Payment Terms :
L/C, D/A, Western Union, T/T, MoneyGram, Paypal
Supply Ability :
5000 units per month
Delivery Time :
within 3 days for 1~20pcs
Packaging Details :
Carton box with pearl sponge
Rated voltage :
12V/24V/48V for optional
Rated Power :
500W
Peak power :
1000W
USB socket :
5V 1A
Warranty :
2 years
Standby consumption :
<7W
Description

DC To AC High Frequency Pure Sine Wave 500W Solar Inverter Price OEM ODM

The 500W solar inverter, designed for off grid solar power system, is an high frequency inverter. It features to converter DC power to pure AC power for any AC appliances, such as a TV, fridge, radio, lights, laptop and so on.

This 500W solar inverter which can generate 300W of continuous power and up to 600W of power at peak times (peak time reserve capacity is useful if more energy is required to start an appliance than for its continuous running).

1. Features

  • Intelligent IC control

  • Unique front and back double soft start technology

  • Core of CUP and the pulse width control technology of SPWM

  • Special constant power output technology

  • Technology of prevent the reverse diode

  • Multiple protection function, such as over load protection, over current protection, high temperature protection, short circuit protection, the battery reverse connect protection, battery over voltage and under voltage protetion, inbuild fuse and so on

  • 100% pure sine waveform output, low distortion, low noise, strong load capacity and so on

  • Buzzer alarm to remind when the 300W power inverter in failure status

2. Parameters

Model YQHI-500W
Rated power 500W
Rated system voltage 12V/24V/48V (optional)
Peak power 1000W
Output voltage 100/110/120/220/230/240VAC, optional
Inverter efficiency >90%
Stand by consumption <7W
Wave form Pure Sine Wave
LED display LED display power&fail status
USB socket Yes, 5V
Fuse

35A (12V), 20A (24V), 15A (48V)
Low voltage alarm 10.5V±0.3V (12V), 21V±0.5V (24V), 42V±0.5V (48V)
Low voltage disconnect 10V±0.5V (12V), 20V±0.5V (24V), 40V±0.5V (48V)
Over voltage disconnect 15.5V±0.5V (12V), 30.5V±(24V), 60V±0.5V (48V)
Over load disconnect 600W (10S)
Over temperature disconnect >75 ℃
Ambient temperature -10℃~50℃
Dimension (mm) 235*146*66
N.W (KG) 1.85
Packing size (mm) 300*180*115
G.W (KG) 2
Warranty 2 years

DC To AC High Frequency Pure Sine Wave Inverter 500W Intelligent IC Control

3. Application

Battery bank system

Solar power system

Car, Bus and so on

4. Packing information

1pcs 500W pure sine wave inverter

1pcs user manual

1pcs connector
