Compact High Frequency Pure Sine Wave Inverter With Dual AC Outlets And One USB Port
Compact High Frequency Pure Sine Wave Inverter With Dual AC Outlets And One USB Port
Compact High Frequency Pure Sine Wave Inverter With Dual AC Outlets And One USB Port
Compact High Frequency Pure Sine Wave Inverter With Dual AC Outlets And One USB Port
Specifications
Brand Name :
Yo Power Electrical
Model Number :
YQHI-1500W
Certification :
CE, ROHS, FCC
Place of Origin :
Anhui, China
MOQ :
10 units
Price :
Negotiable
Payment Terms :
L/C, D/A, Western Union, T/T, MoneyGram, Paypal
Supply Ability :
5000 units per month
Delivery Time :
within 3 days for 1~20pcs
Packaging Details :
Carton box with pearl sponge
Rated voltage :
24V/48V
Rated Power :
1500W
Peak power :
3000W
Display :
LED
Warranty :
2 years
AC outlets :
2pcs
Description

Yo Power 1500W Power Inverter With Dual AC Outlets And One USB Port

Yo Power 1500W Power inverter is an advanced tool of power conversion. It can supply you with AC power converted from any DC power source. It can be used in cars, vessels, during camping and in power failure emergencies. The 1500W Pure Sine inverters are a stable power source with 1500W continuous power and 3000W surge power with low harmonic distortion. This inverter is an excellent tool to use during power failure emergencies and guarantees maximum efficiency with computers, sensitive equipment and more. Compact and portable, this inverter can be used on worksites, boats, cars, camping or for permanent use. The YQHI-1500 features multiple protection function, such as over load protection, over current protection, high temperature protection, short circuit protection, the battery reverse connect protection, battery over voltage and under voltage protetion, inbuild fuse and so on. It also comes with an LED light that indicates the problem.

1. Features

  • DC voltage input: 24V/48V for optional
  • High frequency transformer
  • More than 90% conversion efficiency
  • Pure sine waveform output
  • SMT technology

  • Soft start function

  • Same size, light weight, faint noise ,free maintenance

  • Latest soft-start technique

  • Alloy aluminium case

  • 2 years warranty

2. Parameters

Model YQHI-1500W
Rated power 1500W
Rated system voltage 24V/48V (optional)
Peak power 3000W
Output voltage 100/110/120/220/230/240VAC, optional
Phase Single-phase
Inverter efficiency >90%
Stand by consumption <12W
Wave form Pure Sine Wave
LED display LED display power&fail status
USB socket Yes, 5V
Fuse

20A (24V), 15A (48V)
Low voltage alarm 21V±0.5V (24V), 42V±0.5V (48V)
Low voltage disconnect 20V±0.5V (24V), 40V±0.5V (48V)
Over voltage disconnect 30.5V±(24V), 60V±0.5V (48V)
Over load disconnect 1800W (10S)
Over temperature disconnect >75 ℃
Ambient temperature -10℃~50℃
Dimension (mm) 390*180*90
N.W (KG) 5
Packing size (mm) 430*223*160
G.W (KG) 6
Warranty 2 years

Compact High Frequency Pure Sine Wave Inverter With Dual AC Outlets And One USB Port

3. Application

Portable solar power system, RV power system or other power system with battery

4. Project

1pcs 1500W power inverter

1pcs user manual

1pcs connector
