ABB / Schneider Control High Voltage Solar Charge Controller For Off Grid Solar Power System
ABB / Schneider Control High Voltage Solar Charge Controller For Off Grid Solar Power System
Specifications
Brand Name :
Yo Power Electrical
Model Number :
YQPV-HP series
Certification :
CE, ROHS, FCC
Place of Origin :
Anhui, China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, Western Union, T/T, MoneyGram, Paypal
Supply Ability :
500 units/Month
Delivery Time :
Within 3 days for 1~5pcs
Packaging Details :
Standard exporting wooden case
Type :
High Voltage Solar charge controller
Rated voltage :
192V~600V
Input group No. :
4 groups
Mobile :
Yes
Warranty :
3 years
Display :
LED+LCD
Description

192V ~ 600V 400A Big Power Solar Charge Controller In in Malaysia Phillipines

The 400A Big power Solar Charge Controller is designed for big power system according to the latest technology development and represents the latest photovoltaic technology level. It suitable for most off grid solar generation system which usually install in place where people doesn't have grid power or simply want to be independent from grid power and other fossil energy sources. For more power solar system, user can parallel connect it.

1. Features

  • Infineon IGBT power moduel
  • ABB/Schneider Control
  • Excellent EMC design
  • PWM regulator technology with three-charging stages protect battery from over charging
  • Advanced battery activation technology improve the storage capability of battery and extend battery service life 30% at least compare to other solar controller
  • Users can adjust working parameters according to different type battery
  • Users can parallet connect lots to a system
  • 3'' LCD screen and LED indicators shows charging information
  • New SOC technology shows the generation power of daily, monthly and total
  • RTC function shows the real time and inner side temperature
  • The deep protection to avoid destroying battery when the power switch (IGBT) is down (optional function)
  • 3 years warranty at least

2. Parameters

Rated system voltage 192V 240V 384V 420V 480V 540V 600V
Max. input voltage 384V 480V 768V 840V 960V 1000V 1000V
Rated charging current 200A~400A, optional
Stand-by consumption <0.5W
Equalize charging voltage (absorption) 230.4V 288V 460.8V 504V 576V 648V 720V
Equalize charging time (default setting) 120 minutes
Float charging voltage 220.8V 276V 441.6V 483V 552V 621V 690V
Over voltage disconnect 256V 320V 512V 560V 640V 720V 800V
Over voltage reconnect 240V 300V 480V 525V 600V 670V 750V
Display 3''LCD+LED
Display laguage English
Indicator light Error indicator/Charging indicator
Terminal type TC series terminal
Humidity 0~98%, non-condensing
Storage temperature -25℃~55℃
Elevation ≦4000M, please reduce the power if the elevation high than 4000M
Protection level IP32
Noise <30dBA
Dimension 900*520*500mm
N.W About 75KG
Packing size 540*560*1040mm
G.W About 80KG
Packing information Standard exporting wooden case with pearl sponge
Warranty 3 years at least

Remark: The parameters in red color are adjustable. Users can set them according to different battery demands

ABB / Schneider Control High Voltage Solar Charge Controller For Off Grid Solar Power System

3. Application

The 192V~600V big power Solar Charge Controller works for big power off grid solar power system, users can adjust working parameters to suitable different type of battery, users also can parallel connect lots for big power solar system.

With the PWM regulator technology, the big power solar charge controller can protect battery from over charging, improve the storage capability of battery and extend the battery serive life time.

If you have off grid solar power system and don't know how to choose a suitable solar charge controller, could you please tell us the details, we will recommend suitable model for you and tell you how to connect the solar panels to get a best charging efficiency
