Specifications
Brand Name :
Chanpower
Model Number :
TL-5902
Certification :
CE FCC ROHS
Place of Origin :
Shenzhen China
MOQ :
500
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 sets per month
Delivery Time :
30~35 work days
Packaging Details :
Carton
Solar Panel :
240w
LED :
CREE 80w
Controller :
MPPT Charge Controller
Battery :
LiFePO4
Application :
Square, Garden
Pole Length :
8-12m
Protection level :
IP65
Material :
ABS+Aluminum
Description

Chanpower Outdoor Solar Lights Excellent Performance With LiFePO4 Battery

Feature

  • CE and ROHS certified product
  • Solar Street Light LED Fixture is easy to install and handle for various applications
  • Solar Street Light LED Fixture surface with Polyester Substance
  • Solar Street Light PV Panel,Superior Aluminium alloy material, radiating function is more efficient,make sure long lifespan
  • Solar Street Light PV Panel,Excellent efficiency based on innovative
  • Solar Street Light battery,High temperature performance, electric heating peak is twice that of LiNiCoMnO2 battery
  • Solar Street Light battery, Long service life, using cells with more than 2000 cycles, life expectancy of more than 5 years
  • Solar Street Light battery,Extremely low internal resistance and self-discharge rate
  • Solar Street Light battery,Long life design
  • Battery Box Life span: 20years
  • Solar Street Light Controller,12V/24V automatic identify or user-defined working voltage
  • Solar Street Light Controller,New SOC method of calculating accurately displays the available battery capacity
  • Solar Street Light Controller,IR and MW sensor optional
  • Solar Street Light Controller, Charging battery even in 0 Voltage,activate aromatically.
  • Solar Street Light Pole,Dismountable parts save more shipping space,saving your money.
  • Solar Street Light Pole,Material Q235, mild steel (Q275 Q345 available)




Parameters

Item TL-5902 TL-5902 TL-5902 TL-5902
Light Style Split Split Split Split
POWER 60W 80W 100W 120W
LED Flux 8100~9900 lm 10800~13200 lm 13500~16500 lm 16200~19800 lm
Color Temp 4000~6000K 4000~6000K 4000~6000K 4000~6000K
Brand CREE CREE CREE CREE
Max Power 60W 80W 100W 120W
Life 50000hrs 50000hrs 50000hrs 50000hrs
Solar Panels Largest Wattage 180W
monocrystalline silicon
240W
monocrystalline silicon
300W
monocrystalline silicon
360W
monocrystalline silicon
Life 25years 25years 25years 25years
Battery Type Lithium iron phosphate
battery 1650WH
Lithium iron phosphate
battery 2200WH
Lithium iron phosphate
battery 2750WH
Lithium iron phosphate
battery 3300WH
Life 5-8years 5-8years 5-8years 5-8years
Control Type ChanPower MPPT / PWM ChanPower MPPT / PWM ChanPower MPPT / PWM ChanPower MPPT / PWM
Charge / time valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine
Discharge / time Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs
Lighting Time 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days
Normal Setting 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr]
Light Fixture Materials Aluminium Aluminium Aluminium Aluminium
Style Selectable Selectable Selectable Selectable
Installation Height and Distance Height 6-10M / Distance10-25M Height 6-10M / Distance15-30M Height 8-12M / Distance20-35M Height 8-12M / Distance20-35M
Installation Hole Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM
Pole Type Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø180mm] Cone [Ø60mm/Ø180mm]
Material Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating
Length 6-10M 6-10M 8-12M 8-12M
Thickness 2.5MM 2.5MM 3.0MM 3.0MM
Weight 35-45kg 35-45kg 40-50kg 40-50kg
Flange 250*250mm 250*250mm 300*300mm 300*300mm
Anchor Bolt 2kg 2kg 3kg 3kg


FAQ

Q: Can Chanpower use our my logo on the solar led light products?
A: Yes. Please inform us formally confirm the design before our production.

Q: Do you offer guarantee for the products?
A: Yes, Chanpower offer 3 years warranty to our products.

Q:Can I Get A Lower Price If I Order Large Quantities?

A:Different Order Quantity Different Price, In Addition Any Customized Service Is Available According To Target Price.

Q:Can I Get The Pre-Production solar street controller Sample?

A:Yes, Pre-Production solar street controller Sample Is Available.

Q: How do you ship the goods and how long does it take to arrive?
A: Chanpower usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. By sea or by air optional.

Q:How to deal with the faulty?
A: Firstly, Please send us some pictures or videos of the faulty item for our analyzation. Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, Chanpower will send new parts with new order for defective products and Chanpower will assess if it’s necessary to return the faulty item, Chanpower can discuss the solution including recall according to real situation.

Q: How to proceed an order for solar led street light?
A: Firstly,let us know your requirements or application.
Secondly,Chanpower quote according to your requirements or our suggestions.
Thirdly,customer confirms the details and places deposit for formal order.
Fourthly,Chanpower arrange the production.

Q: What about the delivery date?
A: Sample needs 3-5 days, mass production time needs 1-4 weeks for order quantity more than one container.

Q: Do you have any MOQ limit for led light order?
A: for solar street light controller, 1pc for sample checking is available
