Specifications
Brand Name :
Chanpower
Model Number :
TL-4402
Certification :
CE FCC ROHS
Place of Origin :
Shenzhen China
MOQ :
500
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 sets per month
Delivery Time :
30~35 work days
Packaging Details :
Carton
Color Temperature :
6000k
LED Flux :
6600lm
Controller :
MPPT Charge Controller
LED :
40watt
Application :
Garden, Yard, Outdoor
MW Sensor :
Optional
Description

Solar Power Lights for Outdoor 55watt, Flux 9075lm, Color Temp 6000K

Feature

  • Average distribution light lens, long pole distance, easy to get the acceptance requirements
  • Solar Street Light LED Fixture with tempered glass,EVA lamination and weatherproof backsheet provide long-life and enhance cell performance
  • Solar Street Light LED Fixture cover, High Stength and High Transparent Toughened Glass
  • Solar Street Light PV Panel,Excellent efficiency based on innovative
  • Solar Street Light PV Panel, with stand heavier snow load and higher wind-pressure.
  • Solar Street Light battery,Good safety, no risk of explosion
  • Solar Street Light battery,Built-in Chanpower designed BMS control circuit to ensure stable operation and high reliability
  • Solar Street Light battery,Extremely low internal resistance and self-discharge rate
  • Solar Street Light battery,Long life design
  • Battery Box Waterproof , IP 67,Antiseptic
  • Solar Street Light Controller,12V/24V automatic identify or user-defined working voltage
  • Solar Street Light Controller,Use MOSFET as electronic switch, without any mechanical switch
  • Solar Street Light Controller,LandStar BP has no keys , The control function and the switch condition of the load can be modified by communication connection
  • Solar Street Light Controller,Support firmware upgrade
  • Solar Street Light Pole,Material Q235, mild steel (Q275 Q345 available)
  • Solar Street Light Pole,Life span: 25years

Outdoor 40 Watt Solar Powered Lights Flux 6600lm Excellent Efficiency


Parameters

Item TL-4402 TL-4402 TL-4402 TL-4402
Light Style Split Split Split Split
POWER 40W 45W 50W 55W
LED Flux 5400~6600 lm 6075~7425 lm 6750~8250 lm 7425~9075 lm
Color Temp 4000~6000K 4000~6000K 4000~6000K 4000~6000K
Brand CREE CREE CREE CREE
Max Power 40W 45W 50W 55W
Life 50000hrs 50000hrs 50000hrs 50000hrs
Solar Panels Largest Wattage 120W
monocrystalline silicon
135W
monocrystalline silicon
150W
monocrystalline silicon
165W
monocrystalline silicon
Life 25years 25years 25years 25years
Battery Type Lithium iron phosphate
battery 1100WH
Lithium iron phosphate
battery 1240WH
Lithium iron phosphate
battery 1380WH
Lithium iron phosphate
battery 1510WH
Life 5-8years 5-8years 5-8years 5-8years
Control Type ChanPower MPPT / PWM ChanPower MPPT / PWM ChanPower MPPT / PWM ChanPower MPPT / PWM
Charge / time valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine
Discharge / time Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs
Lighting Time 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days
Normal Setting 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr]
Light Fixture Materials Aluminium Aluminium Aluminium Aluminium
Style Selectable Selectable Selectable Selectable
Installation Height and Distance Height 5-7M / Distance10-20M Height 5-7M / Distance10-20M Height 5-7M / Distance10-20M Height 5-7M / Distance10-20M
Installation Hole Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM
Pole Type Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm]
Material Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating
Length 5-7M 5-7M 5-7M 5-7M
Thickness 2.5MM 2.5MM 2.5MM 2.5MM
Weight 25-30kg 25-30kg 25-30kg 25-30kg
Flange 250*250mm 250*250mm 250*250mm 250*250mm
Anchor Bolt 2kg 2kg 2kg 2kg

FAQ

Q: Can Chanpower use our my logo on the solar led light products?
A: Yes. Please inform us formally confirm the design before our production.

Q: Do you offer guarantee for the products?
A: Yes, Chanpower offer 3 years warranty to our products.

Q:How to deal with the faulty?
A: Firstly, Please send us some pictures or videos of the faulty item for our analyzation. Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, Chanpower will send new parts with new order for defective products and Chanpower will assess if it’s necessary to return the faulty item, Chanpower can discuss the solution including recall according to real situation.

Q:Can I Get A Lower Price If I Order Large Quantities?

A:Different Order Quantity Different Price, In Addition Any Customized Service Is Available According To Target Price.

Q: How do you ship the goods and how long does it take to arrive?
A: Chanpower usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. By sea or by air optional.

Q: How to proceed an order for solar led street light?
A: Firstly,let us know your requirements or application.
Secondly,Chanpower quote according to your requirements or our suggestions.
Thirdly,customer confirms the details and places deposit for formal order.
Fourthly,Chanpower arrange the production.

Q:Can I Get The Pre-Production solar street controller Sample?

A:Yes, Pre-Production solar street controller Sample Is Available.
