Specifications
Brand Name :
Chanpower
Model Number :
TL-0601 / TL-0602
Certification :
CE FCC ROHS
Place of Origin :
Shenzhen China
MOQ :
500
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 sets per month
Delivery Time :
30~35 work days
Packaging Details :
Carton
PV :
Monocrystalline Silicon
Battery :
lithium
Street Controller :
MPPT/PWM
LED :
55W
Materials :
Aluminium
Pole :
galvanized
Description

Chanpower Solar Based Led Street Lights , 55W Solar Powered Road Lights

Feature

  • Chanpower Manufactured according to international quality management system(ISO9001)
  • Solar Street Light LED Fixture is easy to install and handle for various applications
  • High salt mist and ammonia resistance of LED fixture
  • Solar Street Light PV Panel,Superior Aluminium alloy material, radiating function is more efficient,make sure long lifespan
  • Solar Street Light PV Panel,Strong frame,passing mechanical load test of 5400pa, instead of the normal 2400pa.
  • Solar Street Light battery,Good safety, no risk of explosion
  • Solar Street Light battery,Large capacity, larger capacity than ordinary lead-acid batteries
  • Solar Street Light battery,Echo-friendly: No Cadmium. No leaking
  • Solar Street Light battery,Working temperature: -0 to +60 centigrade
  • Battery Box Life span: 20years
  • Solar Street Light Controller,12V/24V automatic identify or user-defined working voltage
  • Solar Street Light Controller,High efficient Series PWM charging, increase the battery lifetime and improve the solar system performance
  • Solar Street Light Controller,Support firmware upgrade
  • Solar Street Light Controller,Fully encapsulated PCB, IP67 protection
  • Solar Street Light Pole, Q235A superior quality steel for Poles
  • Solar Street Light Pole,New powder paniting methods make sure the surface more smooth, the color can be done as you like.

Chanpower Solar Based Led Street Lights , 55W Solar Powered Road Lights


Parameters

Item TL-0601/0602-40 TL-0601/0602-60 TL- TL-
Light Style Split Split Split Split
POWER 40W 60W 80W 100W
LED Flux 5400~6600 lm 8100~9900 lm 5400~6600 lm 5400~6600 lm
Color Temp 4000~6000K 4000~6000K 4000~6000K 4000~6000K
Brand CREE CREE CREE CREE
Max Power 40W 60W 80W 100W
Life 50000hrs 50000hrs 50000hrs 50000hrs
Solar Panels Largest Wattage 120W
monocrystalline silicon
180W
monocrystalline silicon
240W
monocrystalline silicon
300W
monocrystalline silicon
Life 25years 25years 25years 25years
Battery Type Lithium iron phosphate
battery 1100WH
Lithium iron phosphate
battery 1650WH
Lithium iron phosphate
battery 2200WH
Lithium iron phosphate
battery 2750WH
Life 5-8years 5-8years 5-8years 5-8years
Control Type ChanPower MPPT ChanPower MPPT ChanPower MPPT ChanPower MPPT
Charge / time valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine valid for 6 hours of sunshine
Discharge / time Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs Half Power48hrs,Full Power 24hrs
Lighting Time 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days 12hrs every day 3-5 rainning days
Normal Setting 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr] 5 Time Save Setting,[eg. X% Power Light 1st 4 hours,X% Power Light 2nd 4 hours, X% Power Light 3rd 4 hoursr]
Light Fixture Materials Aluminium Aluminium Aluminium Aluminium
Style Selectable Selectable Selectable Selectable
Installation Height and Distance Height 5-10M / Distance10-25M Height 5-10M / Distance10-25M Height 5-10M / Distance15-30M Height 5-10M / Distance15-30M
Installation Hole Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM Diameter:40-75MM
Pole Type Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm] Cone [Ø60mm/Ø140mm]
Material Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating Galvanized Sheet with Coating
Length 5-10M 5-10M 5-10M 5-10M
Thickness 2.5MM 2.5MM 2.5MM 2.5MM
Weight 35-45kg 35-45kg 35-45kg 35-45kg
Flange 250*250mm 250*250mm 250*250mm 250*250mm
Ground Cage 2kg 2kg 2kg 2kg


FAQ

1) Chanpower provide certificate of quality, detailed installation guide and common problem solution,ensuring the customer to install our products correctly.
2) Chanpower guarantees all the products are inspected properly, no unqualified products delivered. Chanpower strictly fulfill the responsibility of after sales service, being committed to warranty scope, implementing the national regulation for industrial products. Chanpower will recall or exchange the defective products free of charge , but buyers shall provide the application form which includes the defects points(design, material, process) and demonstrates the products are properly installed and used by the Chanpower's instruction .
3) Chanpower promises to provide a solution within 48hours since quality objection raised by customer. Customer shall cooperate with the supplier to check the cause in order to confirm quality problem."

Maintenance

"Chanpower solar street lights are designed to be essentially maintenance free. In certain regions with heavy dust, snow, or extreme dry weather with little rain, however, some lever of maintenance is required to ensure the best condition of the lights.
●Every week: inspect street lights to ensure all lights are working. If there are unlit lights, analyze the cause and conduct repairs.
●Every 2 Months: inspect and clean solar panels which are covered with dust or sand.The best tool to clean is a brush with a long pole. cares should be done to avoid damage
●Every 5-7Years: Replace the solar street light batteries if the voltage drop below normal levels. The battery has an expected life of 5-7 years."
