Specifications
Brand Name :
AHONY or OEM
Model Number :
eGo S20W-150w
Place of Origin :
Guangdong, China
Packaging Details :
carton box
Supply Ability :
50000 Piece/Pieces per Month
MOQ :
10 pieces
Price :
$135.00/pieces 10-49 pieces
Product name :
150W high quality flexible solar panels
solar cell :
Mono 125*125 Cell
Type :
IBC, Customized Solar Panel
Panel Dimensions :
540x1460x3mm
Panel Efficiency :
21.7%
Warranty :
1 year
Colour :
white or black
Surface :
ETFE
ETFE type :
shinny or rough ETFE
Eyelet :
Stainless steel
Quality level :
high premium
Certificate :
CE ROHS ISO9001
Description

High Quality Flexible Solar Panels 20W 50W 70W 100W 120W 150W For Yacht Boat RV Roof Top

Product Description

ultralight photovoltaic panel flexible solar panels eGo S flexible solar panel uses high efficiency solar cell,USA back contact SunPower cell,cell efficiency is from 22.4% to 23.7%.ETFE surface from Japan,it can resist high temperature at 242℃,material transmittance is over 95%.More over,it has excellent tensile strength,low water absorption,makes the flexible panel higher waterproof.


eGo S is more flexible than conventional cell flexible like eGo P,it can bend 30° arc at maximum,It’s aerodynamic design that can reduce wind resistance when install on rooftop of RV or yacht.

eGo S is perfect marine hot sale ultralight fotovoltaic panel flexible solar panels for yacht boat rv roof top with high efficiency cell for all mobile use like caravan,boat,marine,motor etc.There are different power and size from 7w to 150w.Also two colours white and black can be used for any panel.Currently flexible solar panel is widely used for mobile,marine,camping industry,Now more and more people concern about eGo S flexible.

Popular models
eGo S 50W
eGo S100W
eGo S 110W
eGo S 150W

Model No. eGo S20w eGo S35w eGo S50w eGo S80w eGo S90w eGo S110w eGo S120w eGo S150w
Product Name Semi-Flexible Solar Panel marine hot sale ultralight photovoltaic panel flexible solar panels for yacht boat RV roof top with high efficiency cell
Maximum Power[Wp] 20 35 50 80 95 110 120 150
Solar Cell SunPower Maxeon Gen III Back Contact Cell
Cell Array[Pcs] 2*16 3*12 4*8 4*9 4*7 4*8 4*9 4*11
Cell Efficiency 22.60% 22.60% 22.60% 22.60% 22.60% 22.60% 22.60% 22.60%
Size[mm] 480x280x3 400x565x3 540x560x3 540x840x3 540x940x3 540x1060x3 540x1200x3 540x1460x3
Max Power Voltage Vmp[V] 18.56 18.56 18.56 18.56 18.56 18.56 20.88 25.52
Max Power Current Imp[A] 1.08 1.89 2.69 4.31 5.12 5.93 5.75 5.88
Open Circuit Voltage Voc[V] 21.90 21.90 21.90 21.90 21.90 21.90 24.64 30.11
Short Circuit Current Isc[A] 1.16 2.04 2.91 4.66 5.53 6.40 6.21 6.35
Net.Weight[kg] 1.1 1.1 1.1 1.1 1.1 1.5 1.9 2.8
Power tolerance[%] ±5% ±5% ±5% ±5% ±5% ±5% ±5% ±5%
NOCT[℃] 45±2 45±2 45±2 45±2 45±2 45±2 45±2 45±2
Operating Temperature[℃] -40/+85 -40/+85 -40/+85 -40/+85 -40/+85 -40/+85 -40/+85 -40/+85
Temperature Coefficient Pmax[%/K] -0.3 -0.3 -0.3 -0.3 -0.3 -0.3 -0.3 -0.3
Temperature Coefficient Voc[[%/K] -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV
Temperature Coefficient Isc[[%/K] 0.05 0.05 0.05 0.05 0.05 0.05 0.05 0.05
Maximum System Voltage[V] 100 V 100 V 100 V 100 V 100 V 100 V 100 V 100 V
Maximum Reverse Current[V] 10A 10A 10A 10A 10A 10A 20A 20A
Certification CE ROHS CE ROHS CE ROHS CE ROHS CE ROHS CE ROHS CE ROHS CE ROHS
Surface/Backsheet Japan ETFE/white plastic
Maximum bend radius(θ) 30°
Cables and Connectors PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes round corner R10,with eyelets
Package 1pcs/Polyethylene foam(EPE Foam),then in 1 carton box
Our Services

AHONY offer a series of after sale service of marine hot sale ultralight photovoltaic panel flexible solar panels for yacht boat RV roof top with high efficiency cell:
Install and debug products for customers;
According to the requirements of consumers, carry out technical guidance on the use and other aspects;
Process:
1.Report problem of exact solar products to the salesman you contact or sales manager.
2.After-service Respond, We will check order information (sequence number, model),
record problem, instruct client to inspect the problem by video. Confirm the necessary info if repairing or replacing is needed.
3.Follow up, We will follow up clients whether the problem is solved or whether any further service need.
4.Our sales person,engineer will follow up with customers need,regular feedback on products,to make sure customers are always satisfy with
products and service.

Packaging & Shipping

we produce different sizes package of marine hot salemarine hot sale ultralight photovoltaic panel flexible solar panels for yacht boat RV roof top with high efficiency cell,offer standard individual carton box package and also customize package like carton box,
white box,gift boxes,will meet all your requirements,for solar panel wholesale,retail,online delivery etc.
Please ask our sales representative for packing advice and exact price.
