180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine
Specifications
Brand Name :
AHONY
Model Number :
eRigid MSP180W
Place of Origin :
Guangdong, China
Packaging Details :
corton for 49cell 175W solar panel back contact IBC solar cell for RV Marine Car panel power solar
Supply Ability :
100000 Watt/Watts per Month
MOQ :
4 pieces
Price :
$147.60/pieces 4-49 pieces
Product name :
back contact cell solar panel
Solar panel :
mono solar panel 180w
Panel Dimensions :
920*940*35
Cell size :
125mmx125mm
Panel Efficiency :
24.40%
Type :
IBC, Customized Solar Panel
Solar cell :
Mono 125*125 Cell
Junction Box :
IP67
Application :
RV Marine Car panel power solar
Warranty :
5years
Certificate :
CE ROHS
Port :
shenzhen
Description

180W Solar Panel Sunpower Back Contact IBC Solar Cell For RV Marine Car Panel Power Solar

Product Description

49cell 175W solar panel back contact IBC solar cell for RV Marine Car panel power solar

Product Name eRigid MSP180W
Maximum Power[Wp] 180W
Solar Cell Monocrystalline solar cell
Cell size[mm] 125*125
Cell Array[Pcs] 7*7
Cell Efficiency 24.40%
Size[mm] 915*920*35
Max Power Voltage Vmp[V] 30.0
Max Power Current Imp[A] 6.0
Open Circuit Voltage Voc[V] 35.4
Short Circuit Current Isc[A] 6.48
Net.Weight[kg] 9
Power tolerance[%] ±3%
NOCT[℃] 45±2
Operating Temperature[℃] -40/+85
Temperature Coefficient Pmax[%/℃] -0.3
Temperature Coefficient Voc[[%/℃] -1.74mV
Temperature Coefficient Isc[[%/℃] 0.05
Maximum System Voltage[V] 1000 V
Maximum Reverse Current[V] IR<2-0A
Certification CE ROHS
Surface/Backsheet PET/white plastic
Maximum bend radius(θ) 10°-20°
Cables and Connectors PV-XC502 Jbox IP65,0.9m cable and 1 pair of MC4 connector
Standard Test Conditions STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes round corner R10,with eyelets

180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine

180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine

Packaging & Shipping

180W Monocrystalline Back Contact Solar Panel IBC Solar Cell For RV Marine

Our Services

AHONY offer a series of after sale service:
Install and debug products for customers;
According to the requirements of consumers, carry out technical guidance on the use and other aspects;
Process:
1.Report problem of exact solar products to the salesman you contact or sales manager.
2.After-service Respond, We will check order information (sequence number, model),
record problem, instruct client to inspect the problem by video. Confirm the necessary info if repairing or replacing is needed.
3.Follow up, We will follow up clients whether the problem is solved or whether any further service need.
4.Our sales person,engineer will follow up with customers need,regular feedback on products,to make sure customers are always satisfy with
products and service.
