Specifications
Brand Name :
AHONY or OEM
Model Number :
eMarvel 150w
Place of Origin :
Guangdong, China
Packaging Details :
1pcs per carton box for semi flexible solar panel flower sunflower 40w 50w 60w 80w 110w customize panel size shape for solar tree solar flower
Supply Ability :
10000 Piece/Pieces per Month
MOQ :
4 pieces
Price :
$135.00/pieces 4-99 pieces
Cell size :
158.75mmx158.75mm
Type :
PERC, Flexible
Panel Dimensions :
660*1330*5mm
Panel Efficiency :
15.67%
Warranty :
3 years
product :
flower solar panel
Solar cell :
monocrystalline
Certificate :
S GS,IEC,CE,ROHS,ISO9001
Port :
shenzhen
Description

Semi Flexible Solar Panel Flower Sunflower Customize Panel Size Shape For Solar Tree Solar Flower LED Lighting Project F

Framelss,thin without aluminium frame

Max bend angle 5degree

Walkable and anti skids surface,resistance to hailstone,pressure and longivity.

CE ROHS S GS IEC certified,more than 8month actual test under sunshine and harsh environment test.

Advantage of eMarvel marine solar panel

High efficiency solar cell

AHONY uses leading brand cell and high efficiency A

grade quality back contact cell to insure high and stable output.

Excellent weak light performance and Maximum energy per watt,Deliver the most energy in demanding real world conditions,in partial shade,weak light,and hot temperatures.

Walkable and Anti-slippery

By any means and do not damage cells,the rough antislippery

surface is safer for installation or maintenance.

Longer lifespan 15years guaranteed

Premium weather or moisture resistance,for harsh

environment 15years life guaranteed,over 25years lifespan.

High temp resistance and little power loss

The surface material resists high temperature Flame

retardancy UL94 VTM-0.Rugged and insulated bottom

reduces area touched surface of yacht,RV,cart etc.Enables

air circulation,it cools down panel and get little power loss.

Rigid,thin,light design for widely use

It’s rigid to resist hailstone,semi flexible with bend angle less

5 degree,suitable for off grid use,marine,yacht,RV roof,on

grid home system,parking lot,portable power generator etc.

It’s 1/6 thickness 7/10 the weight of glass solar panel.

AHONY eMarvel series uses leading Japan raw material,high efficiency A grade solar cells and automatically producing

machine,experienced ultralight solar panel producing experience.We offer more added value on power output,

professional test,industrial standard quality control,after sale service and warranty.

-CE ROHS test and certified

-High Temperature test

-High humidity 85% test

-SGS IEC standard Salt Spray test

Scope of Application

eMarvel is specialized marine solar panel for boat or yacht surface;

floating buoys,bimini,deck,sprayhood,cover,sticking on catamaran and trawler hardtops

It's durable for relatively flat surface and need to walk

Model No. eMarvel 20w eMarvel 50w eMarvel 60w eMarvel 80w eMarvel 100w eMarvel 120w eMarvel 150w
Product Name Semi-Flexible Solar Panel
Maximum Power[Wp] 20 50 60 80 100 120 150
Solar Cell A grade mono PERC cell
Cell Array[Pcs] 2*16 2*17 4*8 4*9 3*11 4*9 4*11
Cell Efficiency 21.30% 21.30% 21.30% 21.30% 21.30% 21.30% 21.30%
Size[mm] 350*385*5 350*970*5 350*1035*5 510*910*5 510*1250*5 510*1330*5 660*1330*5
Max Power Voltage Vmp[V] 18.56 18.70 18.56 18.56 18.15 20.88 25.52
Max Power Current Imp[A] 1.08 2.67 3.23 4.31 5.51 5.75 5.88
Open Circuit Voltage Voc[V] 21.90 22.07 21.90 21.90 21.42 24.64 30.11
Short Circuit Current Isc[A] 1.16 2.89 3.49 4.66 5.95 6.21 6.35
Net.Weight[kg] 1.1 1.1 1.1 1.1 1.5 1.9 2.8
Power tolerance[%] ±5% ±5% ±5% ±5% ±5% ±5% ±5%
NOCT[℃] 45±2 45±2 45±2 45±2 45±2 45±2 45±2
Operating Temperature[℃] -40/+85 -40/+85 -40/+85 -40/+85 -40/+85 -40/+85 -40/+85
Temperature Coefficient Pmax[%/K] -0.3 -0.3 -0.3 -0.3 -0.3 -0.3 -0.3
Temperature Coefficient Voc[[%/K] -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV -1.74mV
Temperature Coefficient Isc[[%/K] 0.05 0.05 0.05 0.05 0.05 0.05 0.05
Maximum System Voltage[V] 100 V 100 V 100 V 100 V 100 V 100 V 100 V
Maximum Reverse Current[V] 10A 10A 10A 10A 10A 20A 20A
Flame retardancy UL94 VTM-0
Certification and test CE,ROHS,SGS,IEC,85°C& 85% humidity test
Maximum bend radius(θ) 5°
Cables and Connectors APJB010,2m dual cores cable 2.5mm2 bare at end
Warranty[Years] 3
Standard Test Conditions STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes round corner R10,with eyelets
