Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Sunpower Black Contact Walkable Solar Panel 120 Watt Semi Flexible For RV Marine Boat
Specifications
Brand Name :
AHONY
Model Number :
eMarvel 120W
Place of Origin :
Guangdong, China
Packaging Details :
carton box
Supply Ability :
2000 Piece/Pieces per Month
MOQ :
2 pieces
Price :
$170.40/pieces 2-99 pieces
Solar panel :
Walkable semi rigid solar panel
Cell size :
125mmx125mm
Type :
IBC,Customized Solar Panel
Panel Dimensions :
550*1090*5mm
Panel Efficiency :
24.4%
Warranty :
2 years
Solar Cell :
SunPower Maxeon Gen 7 Back Contact Cell
Certificate :
CE,ROHS,IEC salt mist,High temp humidity test
Port :
Shenzhen
Description

120w Sunpower Black Contact Walkable Semi Flexible Solar Panel Black Off Grid Solar Panel For RV Marine Boat Ocean

Advantage

The eMarvel light marine solar panel uses top quality material and tested in inner lab,under actual sunshine,test in our factory machine,and in the 3rd party laboratory.

Now this light marine solar panel can bend a slightly angle,they are approved by CE,ROHS,S GS,certified under IEC standard.
AHONY uses high efficiency cell 25.4% back contact cells Gen III.We offer a wide ranges of customize service,OEM,ODM,automatically producing line insures better workmanship,faster delivery and more stable quality.
* Walkable and Anti-slippery
* Longer lifespan 15years guaranteed
* High temp resistance and little power loss
* Rigid,thin,light design for widely use
Solar cells can be:
Back contact cell;
Monocrystalline solar cell
HJT,bificial solar cells

Product Description

Model No. eMarvel 120w
Feature solar panel can walk on step on with rough surface anti slippery
Product Name walkable solar panel 120w anti slippery surface rough ETFE from Japan for marine riverside boat yacht
Maximum Power[Wp] 120
Solar Cell SunPower Maxeon Gen III Back Contact Cell
Cell Array[Pcs] 4*8
Cell Efficiency 24.4%
Size[mm] 550*1090*4
Max Power Voltage Vmp[V] 20.1
Max Power Current Imp[A] 5.97
Open Circuit Voltage Voc[V] 23.72
Short Circuit Current Isc[A] 6.45
Net.Weight[kg] 4.9
Power tolerance[%] ±3%
NOCT[℃] 46±2
Operating Temperature[℃] -40/+85
Temperature Coefficient Pmax[%/K] -0.236
Temperature Coefficient Voc[[%/K] -1.74mV
Temperature Coefficient Isc[[%/K] +0.058
Maximum System Voltage[V] 1000V DC
Maximum Reverse Current[V] 10-20A
Flame retardancy UL94 VTM-0
Certification and test CE,ROHS,S GS,IEC,85°C& 85% humidity test
Maximum bend radius(θ) 5°
Cables and Connectors APJB010,2m dual cores cable 2.5mm2 bare at end
Standard Test Conditions STC: 1000W/m², AM 1.5 and cell temp 25°C
Other notes round corner R10,with installation hole
