Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
Specifications
Brand Name :
NACYC ENERGY
Model Number :
Ground Screw
Certification :
SGS, ISO, AS NZS1170, Patents
Place of Origin :
Fujian, China
MOQ :
50 pieces
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500 Pieces per week
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
150pcs/pallet, 2100pcs/20'ft, 4200pcs/40'ft
Type :
Pole Anchor
Color :
Silver
Customized :
Accepted
Length :
1400\1600\1800mm
Surface Treatment :
Hot Dip Galvanized
Material :
Steel
Warranty :
10 Years
Description

Solar Panel Metal Ground Screw Flange Plate Steel Material Solar Ground Screws

Nacyc ground screws, made of Q235 (Hot Galvanizing), can guarantee long service life due to high resistance to corrosion. Our ground screw are installed in a matter of minutes, with no waiting time and immediately usable and able to withstand pressure, and the ground is restored to its original state by simply unscrewing the device. The ground screws are reusable and can be relocated as many times as necessary.

Technical Data:

Length 1400mm 1600mm 1800mm
Out Pipe Diameter 76 mm
Pipe Thickness 3 mm
Weight 8.1kg, 9.3 kg, 10.46kg
Material ISO630 / Din EN10025
Surface Finished Hot Dipped Galv. As standard DIN EN ISO 1461-1999
Connect Style Round flange or square flange or 185mm regular triangle


Key Benefits:

1 .Compatibility with all type of structures.

Our technical department will adapt the head of our ground screw piles to whatever the need of the customer is.

2. High quality.

As a factory owned ISO 9001 certificate, we can provide high quality steel ground stakes with critically inspection.

3 . Foundation solution concrete free.

Easy installation by spiral pilling machine, no digging, no concrete, no waiting, much convenient, cost effective, time saving and environmentally than concrete foundation.

4 . Surround areas remains unspoiled.

The special configuration of our product allows the insertion without performing land preparation works, which allows a significant cost reduction.

5 . Convenient remove, simple and easy to relocate.

One of the main advantages of our ground screw piles is the possibility of removing them, reducing the environmental impact and minimizing the removing costs.

Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel MaterialDurable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material

Durable Solar Ground Screws , Solar Panel Metal Ground Screw Flange Plate Steel Material
