RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting
RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting
RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting
RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting
Specifications
Brand Name :
Hynall
Model Number :
HNS111
Certification :
RED, FCC, RoHS
Place of Origin :
Shenzhen, China
MOQ :
300pcs
Price :
To be negotiated
Payment Terms :
T/T
Supply Ability :
50,000pcs / month
Delivery Time :
3~4 weeks for bulk orders
Packaging Details :
Bubble bag + carton. (color box or blister package also available on request)
Input voltage :
12V DC standard version, 5V, 24V customized version
Input current :
min. 25mA
Usage :
ceiling light, linear light, etc.
Product name :
HNS111
Size :
75.1*27.1*13.8mm
Operation temperature :
-20℃ ~ +70℃
Description

Model name: HNS111 12V DC input dimmable motion sensor

This model is a good choice for your lighting and lighting system. It can be expanded to multiple functions and versions like 0-10v dimming output, high bay max. 12m, daylight harvest function and 5v high low voltage singal used in lighting system etc.

Advantage:

1. Super compact, flexible to be integrated into any suitable fixtures.
2. Dual-processor technology, real Lux-Off & Daylight monitoring function for built-in application.
3. Memory function with one button commissioning, easy operation and user friendly.
4. IR remote commissioning, easy setting and user friendly.

5. Customzied service: Yes

Product Information:

Input voltage: 12 - 24V DC.
Input current: ≥25mA.


*1~10V DC output signal.

* Sink current: Max. 100mA

Detection range up to 12m in diameter.
Mounting height: 3~6m.


Operation temperature: -20 °c ~ + 70 °c.
RoHS compliant.

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting

Permanent ON / OFF function

Press the button, fixture goes to permanent on or permanent off mode, sensor is disabled.
Quit this mode to press“ Auto”,“ Reset” or“ Ambient learn”

Power Dim +/-


Press "Dim+"button to dim up and down the power step by step. Dimming up the power step by step 20%-40%-60%-80%-100%. Press“ Dim -” button to dim down the power step by step 100%-80%-60%-40%-20%.

RC Setting Dimmable Motion Sensor HNS111 Dual Processor 6m Mounting
