LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
Specifications
Brand Name :
Longi
Model Number :
LR5 54HPB
Certification :
IEC ISO
Place of Origin :
China
MOQ :
1 PCS
Price :
$0.14~$0.16
Payment Terms :
L/C, T/T
Supply Ability :
10000+peices/month
Delivery Time :
5-15 days
Packaging Details :
carton pallet 36pcs per pallet/216 pcs per 20' GP/936 pcs per 40°HC
Material :
Monocrystalline Silicon
Cell size :
182mmx182mm
Panel Dimensions :
1722X1134X30mm
Type :
PERC, Half Cell, All Black
Panel Efficiency :
21.5%
Weight :
20.8kg
Dimension :
1722X1134X30mm
Description

Longi Solar 400W Longi 12V Lr5-54Hpb 405W 410W 415W 420W Solar Panel Kit With Solar Battery System Panel

Features

1,Smart Soldering

2,Optimized Electrical Parameters

3,Optimized Module Size

4,Smart Module Packaging and Logistics

5,Gallium-doped Technology

Electrical Characteristics STC:AM1.51000W/m² 25℃ NOCT:AM1.5800W/m² 20℃ 1m/s Test uncortainty forPman:±3%
Module Type LR5-54HPB-400M LR5-54HPB-405M LR5-54HPB-410M LR5-54HPB-415M LR5-54HPB-420M
Testing Condition STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT
Maximum Power(Pmax/W) 400 299.0 405 302.7 410 306.5 415 310.2 420 313.9
Open Circuit voltage (VocM) 3690 34.70 37.15 34.93 37.40 35.17 37.65 35.40 37.89 35.63
Short Circuit Current /lsc/A) 13.72 11.09 13.78 11.14 13.84 11.19 13.91 11.24 13.97 11.30
Voltage at Maximum Power [VmpM 3094 28.74 31.18 28.96 31.42 29.19 31.66 29.41 31.90 29.63
Current at Maximum Power(Imp/得 1293 10.40 12.99 10.45 13.05 10.50 13.11 10.55 13.17 10.59
Module Effidiengy% 20.5 20.7 21.0 213 21.5
Operating Parameters Mechanical Loading
Operational Temperature 40℃~+85℃ Front Side Maximum Static Loading 5400Pa
Power Output Tolerance 0~3% Rear Side Maximum Static Loading 2400Pa
Woc and Isc Tolerance ±3% Hailstone Test 25mm Hailstone at the speed of23m/s
Maximum System Voltage DC1000N[IEC/UL]
Maximum Series Fuse Rating 25A Temperature Ratings (STC)
Temperature Coefficient of Isc		 +0.050%℃
Nominal Operating Cell Temperature 45±2℃
Protection Class Classl
Fire Rating Temperature Coefficient of Voc
Temperature Coefficient of Pmax		 -0.265%/℃
0.340%/℃
ECClassC

LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit

LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit

LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit

LONGI SOLAR LR5 54HIB 400W 405W 410W 415W 420W Solar Panel Kit
