Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Flexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
Specifications
Brand Name :
JYG
Model Number :
JYG-65W-M
Certification :
CE,ROHS
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
Western Union, , T/T, L/C
Supply Ability :
Mini custom solar panels
Delivery Time :
7-15days
Packaging Details :
standard export package 2pcs/carton
Name :
Custom made thin film solar panels thin film solar panels for home use paper thin solar panels
Material :
Polycrystalline/Monocrystalline
Output peak voltage :
65W
Max power voltage :
18V can be customized
Max power current :
3.61A
Application :
home system,light,and so on
Warranty :
25years
Description

Custom made thin film solar panels thin film solar panels for home use paper thin solar panels

> Antireflective glass

> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Service life is as long as 30 years

Solar Cell

> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module

> Anti-PID

Frame

> Conventional frame
> Sliver or color frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength

Junction box

> Conventional standalone edition and engineering custom edition
> IP67 protection level

> Long service life

Model JYG-65W-M
Nominal peak power(Pmax) 65W
Operating Voltage(Vmp) 18V
Operating Current(Imp) 3.61A
Short-circuitcurrent(Isc) 3.94A
Open-cicuit Voltage(Voc) 21.6V
Optimized cell efficiency 19.5%-22%
Size

541*600*18MMcustomized
Operating temperature -40°C to +85°C
Maximum system voltage 1000VDC
NOCT 48°C+/-2°C
Current temperature coefficient %/K 0.06+/-0.01
Voltage temperature coefficient mV/K -(78+/-10)
Power temperature coefficient %/K -(0.5+/-0.05)

Flexible Thin Film Photovoltaic Panels Residential Monocrystalline MaterialFlexible Thin Film Photovoltaic Panels Residential Monocrystalline Material
