12v 100ah 120ah 150ah 250ah 200ah Solar Gel Battery For EPS
12v 100ah 120ah 150ah 250ah 200ah Solar Gel Battery For EPS
Specifications
Brand Name :
ALLIN Solar Battery
Model Number :
AY-09-200Ah Solar Battery
Certification :
CE , SGS, ISO9001
Place of Origin :
Shijiazhuang Hebei China
MOQ :
1-2
Price :
50-2000$/Set,Price needs to be negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000Sets/days
Delivery Time :
3-25days
Packaging Details :
1pcs/pac,Can be customized
Weight :
13.5kg,51KG/80KG,46KG
Voltage :
12v,1.2V 12V 48V
Nominal capacity :
100AH,100AH 120AH 150AH,200Ah
Warranty :
1 Year,2 year
Application :
Solar System,CCTV/Solar System/UPS backup power/Solar Panel system
Color :
Grey,White / Blue
Type :
solar battery 12v 100Ah
Description

New Energy 12v 100ah 120ah 150ah 200ah 250ah Agm Gel Lead Acid Battery For Solar

1. Key Features

Deep cycle maintenance free gel battery.Our products can be used in UPS,solar street light,solar power systems and water pump,etc.
Ideal new energy 12v 100ah 120ah 150ah 200ah 250ah agm gel lead acid battery for solar
Cell Per Unit
6
Voltage Per Unit
12V
Capacity
120AH@10hr-rate to 1.80V per cell @25°c
Weight
32KG
Max. Discharge Current
1000 A (5 sec)
Internal Resistance
3.5 M Omega
Operating Temperature Range
Discharge: -40°c~50°c
Charge: 0°c~50°c
Storage: -40°c~60°c
Normal Operating
25°c±5°c
Float charging
13.6 to 14.8 VDC/unit Average at 25°c
Recommended Maximum Charging Current
20 A
Equalization
14.6 to 14.8 VDC/unit Average at 25°c
Self Discharge
Batteries can be stored for more than 6 months at 25°c. Self-discharge ratio less than 3% per month at 25°c. Please charge
batteries before using.
Terminal
Terminal F5/F11
Container Material
A.B.S. UL94-HB, UL94-V0 Optional

2. Correct charging method of lead-acid battery

(1)the ideal charging time is to consume 60%~80% of the battery power, because the lead acid battery is the most taboo is the telex release of clean when the charge, will lead to plate vulcanization, shorten its life.

(2)Do not wrap the charger with plastic bags or bottles, because it is easy to catch fire when the charger cannot breathe.

(3)try not to use fast charge, if not necessary, do not more than twice a month.

(4)do not knock, so as not to cause trouble.

(5)Use the standard charger to charge.

(6)often use often charge.

3. Product structure drawing

12v 100ah 120ah 150ah 250ah 200ah Solar Gel Battery For EPS

Charge and discharge parameter table

12v 100ah 120ah 150ah 250ah 200ah Solar Gel Battery For EPS

4. Applications :

♦Solar and wind energy storage system

♦EPS and UPS battery backup

♦Signal system , emergency lighting system , security system

♦Telecommunication Equipment

♦Power plant and transmission system

5. Packing:Hard carton packaging

12v 100ah 120ah 150ah 250ah 200ah Solar Gel Battery For EPS
