MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
Specifications
Place of Origin :
Anhui, China
Brand Name :
SUNEVER
Model Number :
SSCM122420
Type :
MPPT
Application :
Charger Controller, Solar System Controller
Work Time (h) :
24H
Max PV Power :
1000W
Max PV Voltage :
60v
Certificate :
CE
Warranty :
12 Months
Battery type :
Lead-acid/Lithium/LiFePO4 Battery
Charge mode :
MPPT Charging
System voltage :
12/24VDC Auto
Rated Current :
10A/20A/30A/40A
Display :
LCD Screen
Protection :
Short Circuit Overload Overvolt Overtemp
Communication :
RS485/GPRS/WiFi/Ethernet
Protection level :
IP32 (Indoor)
Working Temperature( C) :
25 ~+45 (Full Load)
OEM :
Accepted
Packaging Details :
Carton box
Port :
ningbo shanghai
Supply Ability :
1500 Piece/Pieces per Month
MOQ :
2 pieces
Price :
$26.00/pieces 2-49 pieces
Description
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
An intelligent Solar controller designed for the small photovoltaic off-grid power generation system, the controller adopts MPPT charging technology to automatically find the maximum power output of the photovoltaic module to charge the battery. At the same time, it has multiple protection functions, such as floating charge, overcharge, overcharge, etc. It can not only make full use of solar energy resources, but also ensure the safety and reliability of the battery pack. Meet the
technical requirements of the corresponding national standard GB / T 19064-2003

FEATURES of Solar charge controller

1) Adopt high-performance MCU, fully automatic control;
2) MPPT maximum power point tracking charging mode;
3) Low power consumption, 96% charging efficiency;
4) More comprehensive protection functions: battery overcharge
protection, overcharge automatic recovery, underpressure protection,
underpressure automatic recovery, anti-reverse connection protection,
anti-countercharge, overload protection, short circuit protection,
overtemperature protection, lightning protection, etc.;
5) Production in strict accordance with the national standards and
requirements, with stable performance;
6) High temperature resistance, high humidity resistance, salt spray
resistance, lightning protection, wide application scenarios.
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
Model
SWCM122410A
SWCM1224-15A
SWCM1224-20A
PV modules Voc [V]
<60
150-180
300-360
Module arrays input [array]
1
Rated charging current [A]
5-20A
Rated battery bank voltage [V]
12/24V auto detection
High voltage protection
voltage
16.0/32.0
Overdischarge protection
voltage
10.0/20.0
charge efficiency
≥96%
Charging method
MPPT Maximum Power Point Tracking
defencive function
Anti-reverse connection, short circuit protection,
full disconnect and recovery, underpressure protection
and recovery, etc
operating ambient
temperature
-25℃~55℃
quiescent dissipation
≤2W
Communication
RS485/WIFI/GPRS
levels of protection
IP20
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W

Package details

MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
MPPT Solar Charge Controller 12V 24V 20A 30A 40A Regulator for Max PV Power 1000W
Q1:Are you a factory or trade company?
We are a factory who has more than 10 years experience in manufacturing; strong aftersale service team and technical support. Free design according to client requirements.
Q2:Whats the MOQ？ We have stock and semi-finished products with enough base materials for new sampleand order for all models, So small quantity order is accepted, it can meet your require.ment very well.
Q3:Why others price much cheaper? We try our best to ensure our quality to be the best one in the same level price products. We believe safety and effectiveness are the most important.
Q4:Can I have a sample for testing?
Yes, you are welcome to test samples before quantity order; Sample order will be sentout 2-3 days generally.
Q5:Can Iadd my logo on the products?
Yes,OEM and ODM are available for us. But you should send us the Trademark authori-zation letter.
Q6 :Do you have inspection procedures?
100% self-inspection before packing.
