RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger
Specifications
Brand Name :
Sunica
Model Number :
-
Place of Origin :
China
MOQ :
1
Price :
$0.99/pcs-$120/pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5-15
Packaging Details :
box
Place of Origin:: :
Guangdong, China
Charge port and discharge port:: :
Same port
Min. Hole Size: :
T/2mm / 0.2 Mm / 0.15mm
Board Thickness :
1.6mm
Board Size: :
Support Customization
Temperature Protection :
Double temperature
Description

Bms Lithium Battery Protection Circuit Board Pcb 18650 Electric Battery Charger

In recent years,we have been focusing on the professional design and strict quality control of various BMS,committed to providing high-quality,efficient,safe and environmenta friendly intelligent power energy system solutions,and providing customers with all-round battery solutions,including design development and production.

Product Model XLH-EVD-P50S14 XLH-EVD-P50S17 XLH-EVD-P80S14 XLH-EVD-P80S17
Cell System Lithium iron phosphate / ternary / lithium titanate
Number of core strings Adaptive 14 string/17 string
Single cell voltage collection accuracy ±5mV
Total battery voltage collection accuracy ±0.5%@FSR
Current acquisition precision 1%@FSR
Cell temperature collection channel 3Channel
Continuous charging current 40A 40A 80A 80A
Continuous Discharge Current 40A 40A 80A 80A
Pulse Discharge Current 120A/1S 120A/1S 240A/2S 240A/2S
Conductive impedance <1mR
Capacitive load 6000uF
Operating temperature range -30℃~80℃
Recommended Operating Temperature -30℃~70℃
Storage conditions Temperature: -20°C ~ + 45°C
Humidity:5%-95%RH
Cooling Natural cooling
Dimension W130*D88*H18 mm
PACK safety certification Pack OEM IEC62619/CE/RCM/UL2271/CEC
Communication port CAN2.0B*1CH；RS485*1CH；Bluetooth,4G
Parallel connection 4 PACKs
Altitude 3000m
Self-consumption work<50mA Hibernation <100uA
Heating Module MAX200W Heating power

RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery ChargerRCM High 18mm Battery Management System Lifepo4 18650 Electric Battery ChargerRCM High 18mm Battery Management System Lifepo4 18650 Electric Battery ChargerRCM High 18mm Battery Management System Lifepo4 18650 Electric Battery ChargerRCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger

RCM High 18mm Battery Management System Lifepo4 18650 Electric Battery Charger

Q&A
Q1: Are you factory?
A1: Yes, sunica battery is in DongGuan, Guangdong. Welcome to visit us at anytime.
Q2: What’s the warranty of your battery?
A2: 15months being valid from the date of production.
Q3: What is MOQ? A3: No MOQ for new customers. Q4: Can we have the customize design?
A3: OEM/ODM service are available.
