850VDC Off Grid Solar Inverter 70A 80A MPPT Solar Inverter
850VDC Off Grid Solar Inverter 70A 80A MPPT Solar Inverter
Specifications
model :
MITSCN CONTROLER 384V
type :
MPPT inverter
charge mode :
MPPT
System Type ( Voltage) :
384 VDC
Rated Charge Current :
70/ 80A
Max. PV Input Voltage :
850VDC
Place of Origin :
China
Brand Name :
MITSCN
Certification :
ISO
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Solar Panel Carton box by pallet or ply wooden box
Delivery Time :
5-8 working days
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000 Piece/Pieces per Month
Description

MITSCN CONTROLER 384V 70-80A--MPPT

● MPPT charge mode, conversion efficiency up to 99.5%.

● Charging voltage is adjustable；Three stage charge mode.

● Provide humanized function of human–machine interaction,LCD soft light to show main

parameters.

● RS485 or RS232 ( optional) and LAN communication port,IP and Gate address couldbe

defined by the user.

●Modular design and the lifespan is designed to use for 10 years in theory.

● Products comply with UL, TUV, 3C, CE certification requirements.

● 2 years warranty and 3~10 years extended technical service.

General Parameters

System Type ( Voltage) 384 VDC

Rated Charge Current 70/ 80A

Max. PV Input Voltage 850VDC

Charge Mode MPPT ( Maximum Power Point Tracking ), Efficiency ≥99.5%

Input Characteristics

CG Series Auto Recognize the Battery Voltage Range

288~512VDC

Start the Charging Voltage Point

Higher than current battery voltage 20V

Input Low Voltage Protection Point

Higher than current battery voltage 10V

Rated PV Input Power

29120W (70A),

33280W (80A)

Charge Characteristics

Selectable Battery Type :Sealed Lead-Acid, Vented, Gel, Ni-Cd.

Charge Method:3 Stages: Constant Current (Fast charge), Constant Voltage, Floating Charge

Temperature Compensation:14.2V-(the highest temp.-25℃)*0.3

Other Characteristics

Setting Control

MPPT controller or PC software

Load Control Way

Dual time control mode, PV voltage control mode, PV&time control mode, ON/Off control mode

Load Voltage Protection

Lower than low voltage protection point can be set; Cancel the low voltage protection can be set

LCD Display

System Type, PV Voltage, Charge Voltage, Charge Current, Charge Power, Temperature, etc.

Software Control through PC ( Communication port)

RS485, RS232 , LAN

Protection

Input low voltage, over voltage, PV input reverse connection, battery reverse cooection, over

discharge, short-circuit, Over-temp.

Cooling Way: Intelligent fan cooling

Operating Temperature: -20℃ ~ +40℃

Humidity: 0~90%RH ( no condensation )

Safety: CE, RoHS, UL, 3C

Product Size: 500x371x187mm

Net Weight: 15 kgs

Mechanical Protection: IP21

850VDC Off Grid Solar Inverter 70A 80A MPPT Solar Inverter
