Specifications
Brand Name :
Good Future Solar
Model Number :
MG/ZG/YG/JG.ETC
Certification :
CE/ISO/BV/SGS or designated
Place of Origin :
China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000MW per Month
Delivery Time :
30 Working Days after design confirm
Packaging Details :
Neutral packing
Product :
Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket
Driving System :
Slew drive for tracker
Operation Temperature :
-40℃ - 70℃
String-Power :
Yes
Damper :
Included
Material :
Galvanized Steel
Model :
1p or 2p
Control Algorithm :
Astronomical algorithms + Tilt sensor
Description

Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket

Working principle:
1. The structure is simple, the parts are highly pre assembled, and the construction time is saved.
2. Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
3. Strong wind protection, optional with rain cleaning mode, automatic snow removal mode.
4. IP66 aviation plug connection is adopted, and the system is free of debugging.
5. It can communicate with the inverter in real time, read the output data of the inverter and calculate the best tracking angle.
6. Photovoltaic power generation can be increased by 24-43%.

Functions:

1) It can respond to site features and changing weather conditions, and conditions to continuously optimizing the tracking algorithm of each individual row, to make boost solar power system production.
2) The most promising product technology trends in solar today. which help users get more power generated.
3) Simple structure ,easy in installation and debugger application.

Technical Parameters of single axis solar tracking system

Customized Single Axis Tracker Ground Solar Energy System PV Panel Mounting Bracket
Tracking Range 士 60°
Driving System Slew drive, 28VDC motor
Modules per Tracker Max.90 modules per tracker
System Voltage 1000 V or 1500 V
Ground Coverage Ratio ≥ 25%
Power Consumption 0.2-0.5kWh/day
Power Supply Mode Powered by PV strings, back-up lithium battery
Standard Design Wind Speed 18m/s
Module Supported All commercially available modules
Operation Temperature -40℃ - 70℃
Control Algorithm Astronomical algorithms + Tilt sensor close loop
Tracking Accuracy ≤ 1°
String-Powered Yes
Backtracking Yes
Communication Options LoRa wireless /RS 485 cable
Night Position Yes

Good Future Solar is a professional solar power plant tracker supplier specializing in the design, development and production of solar tracking brackets. The company is a professional solar tracker global solution experts, we focus on low cost and low maintenance solution to create maximum value for customers. We are adhering to the concept of continuous in innovation in design and operation, committed to providing innovative technology and providing efficient and good quality solutions and safe products for global solar photovoltaic power plants.
