MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit
Specifications
Brand Name :
Good Future Solar
Model Number :
MG/ZG/YG/JG
Certification :
BV/CE/ISO/SGS.etc
Place of Origin :
China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000MW per Month
Delivery Time :
30 Working Days after design confirm
Packaging Details :
Neutral packing
Product :
Low-cost solar tracker with slew drive tracker kit
System Voltage :
1000V or 1500V
Structure Material :
Hot dipped galvanized & Pre-galvanized steel
Backing tracking :
Provide
Tracking Range :
±60 degree
Desgin :
Provide
Customized Order :
Yes
Min. Order :
10KW
Description

Low-cost solar tracker with slew drive tracker kit

Description

Ground mounting single axis solar tracking system components slew drive solar panel mounting brackets is controlled by the tracking controller, with simple structure, easy installation, flexible response, good reliability and strong fault identification ability. Compared with traditional fixed inclination installation, the generating capacity can be increased by 15%-20% (depending on local conditions).

MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit

MG 1P Tracker 60 Degree Slew Drive Solar Tracker Kit

Advantage:

The structure is simple, the parts are highly pre assembled, and the construction time is saved.
Weight-lifting structure with 5 supporting points, shaped table design combined with a four-link age structure,driven by slewing drive.
Adapt to outdoor environment,working temperature -40~80C°.
Hot-dipped zinc galvanization will extend the work life of the brackets
Independent driving single row design, no linkage rod, strong terrain adaptability and high plot ratio.
Automatic control: The solar tracking system will provide protection automatically for different weather (rain, snow, high winds, etc. )

Technical Parameters
Product Low-cost solar tracker with slew drive tracker kit
Tracking Range 士 60°
Driving System Slew drive, 24VDC motor
Modules per Tracker Max.90 modules per tracker
System Voltage 1000 V or 1500 V
Structure Material Hot dipped galvanized/Pre-galvanized steel
Power Supply Powered by PV strings,back-up lithium battery
Module Supported All commercially available modules
Operation Temperature -30℃ - 60℃
Control Algorithm Astronomical algorithms + Tilt sensor close loop
Backtracking Yes
Night Position Yes

About Good Future Solar

Good Future Solar is a high-tech company in the clean energy industry, registered in China, address: Zhengzhou East New District, Henan Province, China. Our company is committed to provide the solar products of high reliability with competitive price to our domestic and foreign customers. Strive to build our brand in terms of leading technology, high quality and efficient service.
