CE IP66 Slew Drive Gearbox For PV Tracking System Enclosed Housing
CE IP66 Slew Drive Gearbox For PV Tracking System Enclosed Housing
CE IP66 Slew Drive Gearbox For PV Tracking System Enclosed Housing
CE IP66 Slew Drive Gearbox For PV Tracking System Enclosed Housing
Specifications
Brand Name :
HT
Model Number :
SDE12"
Certification :
CE, ISO9001
Place of Origin :
Changzhou, China
MOQ :
1 piece
Price :
USD 280~504 / pc
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 pcs per month
Delivery Time :
15~45 days
Packaging Details :
plywood box
Model :
SDE12
Gear Ratio :
78:1
Color :
Customized
Application :
PV Tracking System
Warranty Period :
5 years
Certificates :
ISO9001, CE
Maintenance :
Free
Description

CE Qualified IP66 Solar Tracker Slew Drive Gearbox For PV Tracking System


Slew Drive Gearbox Description

Enclosed housing slewing drive mainly apply to the relatively high condition for high requirement for dust-proof,rain-proof and anti-corrosion occasion.Presion grade IP66.

Brand Name: Hangtuo

Model Number: SDE12A-78MHD-24RC-REV.A

Material: 42CrMo, QT

Certificate: CE, ISO9001

Warranty: 5 Years

Duty Cycle: 30 Years

Packing: Plywood package

SDE Model Slewing Drive Performance Parameters

SDE Model Performance Parameters
Model Rated Output Torque (N.m)

Tilting Torque

(kN.m)

 Holding Torque (kN.m) Axial Load (kN) Radial Load (kN) Ratio Efficiency

Precision

(degree)

 IP

Working Tep

(℃)

 Self-locking Weight (kg)
3" 600 1.5 5.8 10 15 31:1 40% ≤0.15 66 -40～+80 Yes 25kg
5" 800 6 9.2 16 27 37:1 40% ≤0.15 66 -40～+80 Yes 34kg
7" 2000 7.5 13.2 34 58 57:1 40% ≤0.15 66 -40～+80 Yes 56kg
9" 4300 16 27.2 60 130 61:1 40% ≤0.15 66 -40～+80 Yes 92kg
12" 5800 25 41 77 190 78:1 40% ≤0.15 66 -40～+80 Yes 160kg
14" 6750 48 45 110 230 85:1 40% ≤0.15 66 -40～+80 Yes 224kg
17" 9460 67 54 142 390 102:1 40% ≤0.15 66 -40～+80 Yes 320kg
21" 16000 89 65 337 640 125:1 40% ≤0.15 66 -40～+80 Yes 492kg
25" 21450 112 89 476 950 150:1 40% ≤0.15 66 -40～+80 Yes 705kg
