High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed
Specifications
Brand Name :
URILIC
Model Number :
U-SL1602-120W
Certification :
ETL, DLC, ENEC, TUV, CE
Place of Origin :
SHENZHEN
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS/week
Delivery Time :
5-15 days
Packaging Details :
Carton box
Product Name :
LED Street Light
Power :
120W
LEDs Qty. :
56 pcs
Input Voltage :
90-305V
Efficiency :
143 Lm/W
Lumen :
17160 lm
Light Size :
596x328x90mm
Packing Size :
635x380x148mm
Gross Weight :
5.7kg
IP Rate :
IP66
Description

120W LED Street Light high lumen led street light 17160 Lm with 143 Lm per Watt

Description:

LED street light refers to the street light made with LED light source, which has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed, high color rendering index, etc., and is of great significance for energy saving in urban lighting.

LED street lights are different from conventional street lights in that LED lights have the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response speed, and high color rendering index, which can be widely used in roads.

High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed

Quick Detail:

  1. With air duct heat dissipation design, the overall weight of the product is reduced and the heat dissipation performance is good, reducing light decay and prolonging the life of the light source. The mainstream CHEM modular design reduces maintenance costs for later use.
  2. Low energy consumption, constant current drive, energy saving 60%; overcurrent, overvoltage, lightning, high temperature protection to fully guarantee the product's life and stability.
  3. Rugged and long-lasting, up to 50,000 hours; no need to change fixtures frequently, no routine maintenance required.
  4. Beautiful appearance without dust, protection class IP66.
  5. Fast response, no stroboscopic; wide operating voltage range.
  6. The lamp bead is housed in two 1W dual crystal packages and the dead light rate is reduced by an order of magnitude.
  7. Green and environmental protection, the light source has no ultraviolet, infrared radiation, and no mercury pollution.

Distribution Curve:

High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed

Product Details:

Model U-SL1602
Power 120W
Light Effects 143 Lm/W
Total luminous flux 17160 lm
Color temperature 5000-6000K
Color Rendering Index ≥70
Light source brand Bridgelux / San‘an
Number of light sources 56 pcs
Lighting angle 150*45°/150*65°/150*70°
Protection level IP66
Working voltage 90-305V
Working environment temperature -40°C~50°C, 20%~90% H.R.
Storage temperature -40°C~85°C, 10%~90% H.R.
Power Efficiency 90%
Power factor >0.95
Lighting life >50000H
Light pole size Φ60mm
Light body material AL6063-T5
Lighting size 596*328*90 mm (±5mm)
Package size 625*380*150 mm (±5mm)
Light weight of the fixture 5.7 kg (±0.1kg)

Mechanical Drawing:

High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed

Installation Diagram:

High Lumen Led Street Light Fixtures 120W 17160Lm Energy Saving Fast Response Speed

  1. Open the back board and back cover;
  2. Connect the light wires and grid wires;
  3. Insert the lamp pole into the light, lamp pole dia φ60mm;
  4. Make sure the light is steady, lock the push board M10 Hexagon socket head cap screws, fix the light tightly onto the pole arm;
  5. Close the back board, then back cover. Done;
  6. Connect light power supply wire and grid wire according to above picture, blue to N, brown to L, yellow&green to E.

Applications:

LED Street Light is widely used in urban expressways, highways, trunk roads, secondary roads, access roads, streets, factories, schools, gardens, parks, community, garden plaza and other street lighting.
