High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
High - Tech Solar Wind Hybrid System For Traffic Signal LED Display
Specifications
Brand Name :
URILIC
Model Number :
Mobile Energy Vehicle Solar Wind Hybrid System
Certification :
ISO9001,CE,UL,IEC
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200 sets/ month
Delivery Time :
5-30 work days
Packaging Details :
Multiple packaging
Product Name :
Solar Wind Hybrid System
Solar Panels :
Design as needed
Wind Turbines :
600W, 1000W
Wind Turbine Connection :
Flange connection
Box Material :
Cold rolled steel box
Box Surface treatment :
Surface treatment spray
Usage :
Off Grid, Road Signs, Traffic Signal LED Display
System :
Traffic Signal LED Display Solar Wind Hybrid System
Description

Traffic Signal LED Display Solar Wind Hybrid System Hybrid Power System Road Signs

The wind and solar hybrid traffic LED signal display variable information mark and the variable speed limit mark are all displayed by the pixel tube composed of the LED light-emitting diodes, and the pixel tube dot matrix is formed into a text or a graphic. It is used to display information about roads (accidents, road maintenance, bad weather) and induce traffic.

The wind and solar hybrid traffic LED signal display screen consists of the screen body and internal temperature control, drive system, control system, communication equipment, power supply system and gantry (column) box. By placing it above the roadway or on the side of the road, it can release traffic information for the oncoming vehicles, effectively induce traffic flow, improve the transportation capacity of the road network, promote safe driving, and ensure smooth traffic. the goal of.

The display area is from 800mm x 800mm to 1536mm x 1536mm, which can meet the specific requirements of different road sections. The brightness can be selected from 6500 to 15000nits, showing the red, green and yellow Chinese characters and icons specified by the national standard.

High - Tech Solar Wind Hybrid System For Traffic Signal LED Display

Hot-selling Maglev Vertical Axis Wind Turbine:

Items

60024/48

100024/48

Rated power

600W

1000W

Dimension
(Height/Diameter)

Ø1100/1250

Ø1500/1760

Weight

32kg / 35kg

55 kg / 57kg

Blade material

Aluminum Alloy

Aluminum Alloy

Blade quantity

3

3

Swept area ㎡

1.2

1.8

Min starting wind speed

1.3m/s

1.5 m/s

Cut-in wind speed

2 7m/s

3.5m/s

Rated wind speed

12m/s

13m/s

Cut-off wind speed

15m/s

15m/s

Survival wind speed

65m/s

60m/s

Generator type

AC,3Phases

AC,3Phases

Controller Output Voltage

24V/48V

24V/48V

Controller Braking System

3-phase short circuit by NFB brake

3-phase short circuit by NFB brake

Ambient Temperature

-40～50 ℃

-40～50 ℃

Noise

Noisy from National Machinery Quality Inspection Centre at 12m/s : <40db

System Features:

The wind-solar complementary or solar-powered LED display system is a new type of green high-tech product. It absorbs natural wind and solar energy to power the display equipment. It does not need to be supplied by the city. It is not restricted by the installation area. It does not need to lay the power supply cable. Installation and post-maintenance are very convenient and the overall benefits are good. As an environmentally friendly, non-polluting clean energy source, wind energy is cost-effective, easy to install and maintain, and will gradually replace the traditional power supply method. Generally, highways, national highways, urban roads, roads and trunks of major highways, urban highways, streets, airports, terminals, stations and other transportation sites are used.
  • Advanced: Adopt advanced design ideas combined with exquisite craftsmanship to ensure the advanced nature of the system.
  • Performance and price ratio: The system is easy to operate, easy to maintain, and the software can be easily upgraded to protect the owner's investment. Strive to achieve the most cost-effective display.
  • Practicality: It can meet the requirements of graphic and text information display, and can timely release on-site road conditions, latest notifications and other information.
  • Ornamental: Unique design of the display. It not only ensures the function of the display is perfect, the structure is reasonable, the appearance is modern, and the atmosphere.
  • Reliability: High-efficiency lighting device, high-quality LED driver chip, the whole system adapts to the harsh outdoor environment, software and hardware can run stably for a long time.

Solar Panels Configuration:

Model U280M-20 U285M-20 U290M-20
Peak Power (W) 280±3% 285±3% 290±3%
Open circuit voltage (V) 38.2 38.2 38.2
Peak Voltage (V) 31.5 31.5 31.5
peak current (A) 8.89 9.08 9.20
Short-circuit current (A) 9.51 9.68 9.85
Cell efficiency 19.6% 20.0% 20.4%
Component Efficiency 17.1% 17.4% 17.7%
Maximum overcurrent (A) 15A
Maximum system voltage (V) 1000V DC
Rated operating temperature 48±2°C
Working temperature range -40°C- +85°C
Current temperature coefficient 0.1%/°C
Voltage temperature coefficient -0.37%/°C
Power Temperature Coefficient 0.45%/°C
Solar Cell 156*156*0.19mm
Number of cells 60 pcs
Size 1650*992*35mm
Weight 19.0 kgs
Surface Packaging Low iron tempered glass/3.2mm
Sealant Ethylene Vinyl Acetate (EVA)
Border Anodized Aluminum/Silver
Junction Box Waterproof Level ≥IP65
Pre-wind pressure 2400Pa
Back wind pressure 2400Pa
Maximum hail impact 25mm/ 23m/s
