Specifications
Brand Name :
URILIC
Model Number :
30W
Certification :
UL,CE
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS/week
Delivery Time :
5-15 days
Packaging Details :
Plywood box
Product name :
monocrystalline solar module
Power :
30W
Size :
540*340*18mm
Weight :
2.0kg
Connector :
MC4
Junction box :
≥ IP 65
Frame color :
Silver or Black
Front cover :
3.2mm High Transmission low Iron tempered glass
Description

30W-18V Small Solar Panels Power Monocrystalline Silicon Solar Panels

Description:
Small solar panels can be applied to portable solar power, solar garden lights, solar traffic lights, small wind and solar hybrid power generation systems and other application scenarios. Monocrystalline Solar Panels have been the go-to the choice for many years. They are among the oldest, most efficient and most dependable ways to produce electricity from the sun. Each module is made from a single silicon crystal and it is recognized by their colour, which is typically black or iridescent blue.

Features:

  1. High efficiency monocrystalline solar power panel.
  2. Outstanding low-light performance.
  3. High transmission tempered glass ensure high quaility solar panel.
  4. Solar cells solar panel with durable anodized aluminum frame.
  5. Efficient protection from frame deformation and water accumulation.
  6. Rugged design to withstand high wind pressure and snow load, easy installation.


Product Details:

ModelU-30M-12
Peak Power (W)30±3%
Open circuit voltage (V)21.6
Peak Voltage (V)18.0
peak current (A)1.67
Short-circuit current (A)1.81
Cell efficiency21.3%
Maximum system voltage (V)1000V DC
Rated operating temperature48±2°C
Working temperature range-40°C- +85°C
Current temperature coefficient0.1%/°C
Voltage temperature coefficient-0.37%/°C
Power Temperature Coefficient0.45%/°C
Solar Cell156*26*0.19mm
Number of cells36 pcs
Size540*340*18mm
Weight2.0 kgs
Surface PackagingLow iron tempered glass/3.2mm
SealantEthylene Vinyl Acetate (EVA)
BorderAnodized Aluminum/Silver
Junction Box Waterproof Level≥IP65
Pre-wind pressure5400Pa
Back wind pressure2400Pa
Maximum hail impact25mm/ 23m/s


Small 30W Monocrystalline Solar Module 18V Mono And Poly Solar Panels

30W-18V small solar panel assembly size chart

Our advantage:

  1. High conversion efficiency, high-transmission rate.
  2. Energy saving, environmental-friendly, Safty, No pollution.
  3. Advanced technology, strict quality control system.
  4. Easy installation, safe operation, free maintenance.
  5. 10-year product warranty,12-year warranty at 90% power output,25-year warranty at 80% power output.
  6. Quality in priority, clients the upmost.
Solar Panel Details Show:

Small 30W Monocrystalline Solar Module 18V Mono And Poly Solar Panels

Solar Cell

High Efficiency PV Cells
Appearance Consistency
Color sorting ensure consistent appearance on each module
Anti-PID

Frame

Frame thinkness>18mm

Oxidation Film>15Pm

TUV&UL standard sillica gel

Ability to resist 5400Pa mechanical pressure

Good anti-corruption performance in seaside environment

Solar junction box

PPO material, IP67.
Quality diode ensures module running safety

Heat dissipation

Long service life

Small Solar Panel Application:

Small 30W Monocrystalline Solar Module 18V Mono And Poly Solar Panels

Solar Motion Light

Solar Camera

Small Solar Power Generation System

Household Solar Panel
