Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve
Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve
Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve
Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve
Specifications
Brand Name :
NAESEL
Model Number :
NLZ11100GLN
Certification :
CE ROHS FDA TUV
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, L/C, Paypal, MoneyGram, Western Union,
Supply Ability :
10000PCS Per Month
Delivery Time :
2-7 days
Packaging Details :
Solid paper cartons, with box with your logo or QR code
Material :
Stanless Steel SS304 SS316
Character :
Close slowly anti hammer
Medium :
Water
Structure :
Piston Actuated
Pressure :
0.3~1.0Mpa (43~145Psi)
Connect ends :
3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"
Port Thread :
G or NPT thread
Orifice :
20, 25, 40, 50, 80(mm)
Voltage :
AC220V, AC110V, AC24V, DC24V, DC12V
Seal :
PTFE or Imported High Temperature Seal
Fluid Temperature :
-10~250℃（14~482℉）
Application :
Food or Beverage Pipe Line,
Ambient Temperture :
-10~60℃(14~140℉)
Actuator Diamter :
50, 63, 80, 100, 125(mm)
Connection Style :
G, Clove, Clamp, Flange or Welding
Description

Inline Inline Non Return Valve SUS316 Stainless Steel DN25 1 Inch NPT Spring Return 50 Mil FilterNon Return Valve SUS316 Stainless Steel DN25 1 Inch NPT Spring Return 50 Mil Filter

1. How To Order

Model Orifice Connection Body Actuator Actuator Diamter Seal

NLQ11 10, 15, 20, 25 G-Thread S-Stanless Steel S- Stanless steel 50,63,80,100, 125(mm) P-PTFE

32, 40, 50, 65 K-Cloves B-Brass E-EPDM PA-Polyamide V-Viton

80, 100 F-Flange A-Aluminum

H-Welding

NLQ11 Inline Non Return Valve SUS316 Stainless Steel DN25 1 Inch NPT Spring Return 50 Mil Filter

Example : NLQ11 15 GSPA50P : NLQ11 Series, 15mm orifice, G1/2", Stanless stell body, PTFE seals, Polyamide Actuator,

50mm Actuator diameter with PTFE seal.

2. Solenoid Valve Specification

Medium: Water, Neural Gas, Ethyl Alcohol, Oil, Organic Solvent,

Temperature: NBR seal:-10℃~80℃(14℉~176℉) Orifice: 10, 15, 20, 25, 32, 40, 50, 65, 80, 100(mm)

Viton seal:-30℃~150℃(-22℉~302℉)

EPDM seal:-30℃~120℃(-22℉~248℉)

Pressure: 0.0MPA~1.6MPA (0.0PSI~230PSI) Port size: 3/8”, 1/2", 3/4", 1", 1-1/4", 1-1/2”, 2”, 3”, 4"

Connection: Thread, Flange, Cloves, Flange Port thread: G Thread, NPT thread

Material: Body- AISI316 Character: 1. Water Hammer Prevention Design

Seal- PTFE 2. Multi Connecion Choices

Armature- SS304 3. Piston Allow more Flow & Require Less Air Consumption

Plunger- SS430F 4. Self-lubrication Piston Rod with Longer Service Life

4. Diemsion

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

5. Packing Detail

Plastic Sealed packing to prevent metal being oxidized.

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

6. More Product Photo and Certifications

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

7. Factory Photos and Certifications

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

Inline Non Return Valve , Spring Return 50 Mil Filter Smc Pilot Valve

7. Why US?

Our core advantages to pursue Your Success.

1.Reliable Quality (We are OEM supplier of ASCO and Parker)

2.Over 20 years solenoid valve design and customize experience.

3.Mark Service(both Product and packing wiht your design and logo)

4.Related Supply Service, including Festo, SMC, , Airtac, Shako.

5.Good English communication

6.Opening Mind to growing with clients for different products.

(please continue reading to find out more detail)
