Water Screen Solenoid Valve Brass as Need DC 220V 12V 1 / 8 1 / 4 NPTWater Screen Solenoid Valve Brass as Need DC 220V 12V 1 / 8 1 / 4 NPT

Water Screen Solenoid Valve Brass as Need DC 220V 12V 1 / 8 1 / 4 NPT

1. How To Order

Model Orifice Port Thread Body Seal Coil Voltage

NLHO 50-5.0 mm 1--1/8" G- G B-Brass N-NBR S11B 1-AC220V 2.DC24V

60-6.0mm 2--1/4" N- NPT S-SS304/316 V-FKM 3-AC110V 4.DC12V

11-10.0mm R- BSPT Aluminum 5-AC24V 6-DC6V

Water Screen Solenoid Valve Brass as Need DC 220V 12V 1 / 8 1 / 4 NPT

Example : NLHO11 GBN S11B1: NLHO11 Series, Normal closed, 5mm orifice, G1/2", brass body, NBR seals, Coil S11B, AC220V.

2. Solenoid Valve Specification

Medium: Air, water, etc. Temperature: NBR seal:-10℃~80℃(-22℉~302℉)

Orifice: 5,6, 10 (mm) Viton seal:-30℃~80℃(-22℉~302℉)

Pressure: NLHO:0.00MPA~0.1MPA (0.0PSI~14.5PSI)

Port thread: NPT, G Thread Port size: 1/8”, 1/4”,

Voltage: DC:6VDC,12VDC, 24VDC, 36VDC, Coils: S11B 13VA(AC),11W(DC),Coil IP68,100%ED

AC:24VAC, 110VAC, 120VAC, 220VAC, 240VAC

Tolerance: ±10% Character: 1. Compact design to save the space.

Material: Body- Brass, stainless steel, Aluminum, 2. Direct acting, 0 bar generated.

Seal- VITION, NBR,

Armature- SS304

Plunger- SS430F

Stop- SS430F

Spring- SS304

Shading Rings- Copper

Special Coils: Latching coil DC6~24V

3. Dimension

4. Specification Detail

Water Screen Solenoid Valve Brass as Need DC 220V 12V 1 / 8 1 / 4 NPT

5. Packing Detail

Plastic Sealed packing to prevent metal being oxidized.

6. More Product Photo and Certifications

7. Why US?

Our core advantages to pursue Your Success.

1.Reliable Quality (We are OEM supplier of ASCO and Parker)

2.Over 20 years solenoid valve design and customize experience.

3.Mark Service(both Product and packing wiht your design and logo)

4.Related Supply Service, including Festo, SMC, , Airtac, Shako.

5.Good English communication

6.Opening Mind to growing with clients for different products.

(please continue reading to find out more detail)
