Vacuum Absorbing Automatic Chamber Filter Press 750L Vertical Filter Press
Vacuum Absorbing Automatic Chamber Filter Press 750L Vertical Filter Press
Vacuum Absorbing Automatic Chamber Filter Press 750L Vertical Filter Press
Vacuum Absorbing Automatic Chamber Filter Press 750L Vertical Filter Press
Specifications
Brand Name :
UNIVEE
Model Number :
U-PF
Place of Origin :
China
MOQ :
1 set
Price :
Customized
Payment Terms :
T/T, L/C
Supply Ability :
10 sets per month
Delivery Time :
4-6 weeks
Packaging Details :
Steel frame, Wooden Case, Tray, Suitable for multi transpiration
Name :
Plate Type Filter
Plate Quantity :
17~82 pcs
Application :
Pharmacy, Coal, Sewage etc
Frame :
Supporting Frame
Mateiral :
MS
Condition :
New
Vacuum :
Adopted
Service :
Available
Description

Vacuum Absorbing Filtration Press Filter Chamber Volume 750L Vertical Filter

Product Description:

Filter press is a common solid-liquid separation equipment, using special filtering medium to press on the object and dialyze out the liquid.

The filter plate is consisted with diaphragm plate and side plate. Tow sides of diaphragm base plate are covered by rubber diaphragm. Then cloth is on outside of it. The slurry enters into the press filter and flows from the holes of thrust plate. Solid size bigger than the medium or cloth is blocked in the filtration chamber. The filtrate is flows out from the bottom drainage holes of filter plate.

Cake dewatering can not only adopt diaphragm pressing but also use air compressor or steam, the air flows from the washing inlet, and remove the moisture from the cake to reduce the moisture content.

Vacuum Absorbing Automatic Chamber Filter Press 750L Vertical Filter Press

Features:

Stable operation
Low consumption
Widely applicated in different area for different cake moisture requirement
Integrated PLC, HMI and automatic instrumentation control system, intelligent, hi-efficient, more conveniency
Cloth washing more cleanly
Reasonable design structure

Technical Parameters:

Filter Area (㎡) Outer Plate Slze (mm) Inside Frame Size ((mm) Cake Thickness (mm) Number of Plate and Frame (Pair) Chamber Volume (L)
20 900x900 800×600 30 17 300
30 25 450
40 33 600
50 41 750
60 50 900
70 58 1050
80 66 1200
100 82 1500

Support and Services:

Our team of experts is available to assist with installation, operation, maintenance, troubleshooting, and repairs.

Packing and Shipping:

UNIVEE has rich experiences of products packing, loading and delivery for mutli-transporation.

Type of Packing:

Packed in Crate / Wooden Case / Tin Lined Wooden Case / Plywood Case.
Packed with fumigation package
Packed in plastic lorap, double bister and jute rope

FAQ:

Q: What is the brand name of this product?

A: The brand name of this product is UNIVEE.

Q: What is the model number of this product?

A: The model number of this product is U-PF.

Q: Is this product easy to clean?

A: Yes, this product is easy to clean. Simply remove the filter and rinse it with water.
