Chamber Stainless Steel Filter Press Sludge Dewatering Filter Press
Chamber Stainless Steel Filter Press Sludge Dewatering Filter Press
Chamber Stainless Steel Filter Press Sludge Dewatering Filter Press
Chamber Stainless Steel Filter Press Sludge Dewatering Filter Press
Specifications
Brand Name :
UNIVEE
Model Number :
U-PF
Place of Origin :
China
Certification :
ISO
MOQ :
1 set
Price :
Customized
Payment Terms :
T/T, L/C
Supply Ability :
10 sets per month
Delivery Time :
4-6 weeks
Packaging Details :
Steel frame, Wooden Case, Tray, Suitable for multi transpiration
Color :
Customized
Filtrate Area :
60-100m2
Filter Type :
Mesh
Roller Press :
Yes
Spout Type :
Narrow
Condition :
New
Service :
Available
Warranty :
1 Year
Description

Stainless Steel Frame Chamber Filter Press Sludge Dewatering PP cloth filter Blue Color

Product Description:

The Press Filter is perfect for pressing liquids from solids. It is designed to exert pressure on the solids, pressing out the liquids and discharge the requried solids.

lt makes full use of the slurry feeding pump pressure, slurry properties and rubber diaphragm extrusion pressure, and use filter cloth as filter medium to separate the solid and liquid from slurry.

Chamber Stainless Steel Filter Press Sludge Dewatering Filter Press

Features:

Reliable operation
Integrate filtering, extrusion, washing, air-drying, cake discharging and cloth washing together.
Big extrusion pressure
Stable operation
Low consumption
Automatic control
High efficient
Easy operation
Better cloth washing effecient

Technical Parameters:

Filter area (m2) 18 24 30 36 42 48 54 60 66
Plate size (mm) 3.0m/layer
Plate Qty. (layer) 6 8 10 12 14 16 18 20 22
Length (m) 5.1
Width (m) 5.5
Height (m) 4.3 4.5 4.9 5.4 5.8 6.3 6.8 7.2 7.7
Weight (T) 31 33 35 37 39 41 43 45 47
Hydraulic station power (KW) 22
Extrusion pump flowrate (m3/h) 40 55
Extrusion pump head (m)

136

Nole: if extrusion pressure more than 1 3MPa, this data is 162

135

Note: I extrusion pressure more than 1 3MPa, this data is 166
Extrusion pump power (KW)

15

Note: if extnusion pressure more than 1.3MPa this datais 18.5

22

Note: it extrusion pressure more than 1 3MPa. this data is 30

Applications:

  • Food and Beverage Industry
  • Chemical Industry
  • Pharmaceutical Industry
  • Environmental Industry

​

Packing and Shipping:

Product Packaging:

The filter cloth product will be packaged securely in a cardboard box with protective padding to prevent any damage during shipping. The box will be clearly labeled with the product name and any other necessary information.

Shipping:

The filter cloth product will be shipped via standard shipping. For expedited shipping options, please contact customer service.

FAQ:

Q: What is the brand name of this press filter?

A: The brand name of this press filter is UNIVEE.

Q: Where is this press filter manufactured?

A: This press filter is manufactured in China.

Q: What is the material of this press filter?

A: The material of this press filter is stainless steel.
