1 . High resolution:1440dpi,vivid output .
2 . Keeping efficient productivity .
3 . Stable quality,no headache .
4 . Easy conrol and maintain.
Product Specification:
MODEL | UD-1612LC | |
Printhead | Epson DX5 | |
Number of printhead | 2 Heads | |
Maximum print width | 1,600mm | |
Print Speed (m2/h) | Print mode | Output(m2/h) |
R Draft 2pass | 53 | |
Draft 3pass | 35 | |
Standard 4pass | 26 | |
Quality 5pass | 17 | |
High Quality 6pass | 13 | |
Back-Lit 12pass | 8 | |
Ink | Type: | Water based / Eco Solvent Ink |
Color : | 4 Color (C,M,Y,K) | |
Capacity: | 1L per Main Tank of Each Color | |
Ink Supply System | Auto Ink Supply System | |
Media Width | Maximum 1,680mm |
MODEL | UD-1612LC |
Media Type | Vinyl, Polyester, Flex, Back-lit Film, PS Board, KT Board, PVC Board, etc. |
Auto Media Feeding System | Equipped (Max. Media Weight 25kg) |
Auto Cleaning System | Anti-clogged Flash Function & Capping System |
Pre-heating & Drying System | Equipped |
Clamp | Equipped |
Print Interface | USB 2.0 |
Printhead Height | 2 to 6 mm from Media |
RIP Software | Ultraprint, Maintop, Photoprint, Wasatch, Ergosoft |
Input Power | AC 220V, 50Hz/60Hz |
Machine Dimension / N.W | L2,820 x W990 x H1,260mm / 200KG |
Package Dimension / G.W | L2,860 x W1,050 x H685mm / 377KG |
Attentions for operating printer
1. Don’t plug off printer power supply or other related data cable before printer power supply has been turned off.
2. To avoid the unnecessary loss caused by behind cleaning the tools or other articles which put on the print table or cover of printer by careless after machine running., Do not put tools or other articles on printer table or cover.
3. Make sure the carriage has been fixed on the original place before moving printer.
4. Attentions for installation and use environment
The printer should be positioned stably and levelly, and well for ventilation, for easier plug on/off, Place your printer close to wall outlet. Don’t exposure printer under sunlight, highlight or other heat sources to keep a good temperature and humidity environment. Using temperature:18-30°C ; Humidity:40%-80%. For best printing status, air conditioner and thermometer are required. Printer must far away from strong radiation interference source.UPS and power stabilizer (power above 1500W) is suggested to adopt.
5. Attentions for Ink placement and using
Ink should be out of reach of children to prevent them touch or inhale in, washing with soap and water if ink contact with skin; washing with fluid water immediately if ink contact with eyes; to avoid ink leakage, don’t shaking the ink bottle; after a period (2 months) of using, ink bottle should been cleaned and dry in the air,cleaning printer before replace new ink bottle to make sure printing quality. Store ink in a cool place and don’t exposure under sunlight
Why order from us?
1 . Our profession is infiniti/challenger/phaeton printers. Quality is good, product from factory directly.
2 . We save a lot in our stock,can deliver to you fast.
3 . I am an engineer of these printers, will help you to install machine and software,solve all the
problem of your new printer and old printer.
4 . If you have freight forwarding in Guangzhou,we will deliver product to their warehouse free for you.
5 . Equipments have one year warranty.
6 . Our idea is treating client as friend,will cooperate with you by our heart.
We are professional supplier to oversea, that have your inquiry,it is our pleasure to service for you!
