8 Channels CWDM Mux Demux, 1470-1610nm, with Monitor and Expansion Port, 2.0dB Typical IL, LC/UPC, Dual Fiber
8 Channels CWDM Mux Demux, 1470-1610nm, with Monitor and Expansion Port, 2.0dB Typical IL, LC/UPC, Dual Fiber
Specifications
Brand Name :
SONBORN
Model Number :
SN-CWDM-MD-D8
Certification :
CE FCC ROHS
Place of Origin :
CHINA
MOQ :
1PC
Price :
Please contact us
Payment Terms :
T/T
Supply Ability :
5000PCS
Delivery Time :
5~8 Workdays
Packaging Details :
Cartons
Wavelength :
8 Channels
Channel Spacing :
20nm
Insettion Loss(dB) :
≤ 2.4dB, 2.0dB Typical
Temperature :
Operating -40 to 85°C (-40 to 185°F) Storage -40 to 85°C (-40 to 185°F)
Return Loss :
≥45dB
Description

8 Channels CWDM Mux Demux, 1470-1610nm, with Monitor and Expansion Port, 2.0dB Typical IL, LC/UPC, Dual Fiber

The 8CH Mux Demux is a high-density, low loss, and suitable for long-haul transmission passive DWDM device based on TFF (Thin Film Filter). This unit can be used as either a multiplexer or de-multiplexer (mux/demux). In accordance with the ITU-T G.694.1 100GHz grid, it maximizes the capacity of the C-band range.

Features

  • Low insertion loss
  • Broadband transmission
  • High isolation
  • High stability and reliability

  • Epoxy glue

Application

  • Metro/Access networks
  • WDM system
  • Fiber optical amplifier
  • CATV system

Specification

Parameter Value
CWDM Channels Number 通道数 8 16
Operation Wavelength (nm) 工作波长 1270-1610
Center wavelength accuracy (nm) 中心波长精度 ± 0.5
Channel Spacing (nm) 信道间距 20
Passband (@-0.5dB bandwidth)(nm) 信道通频带 ±7 & ±6.5
Insertion Loss(dB)插入损耗 2.5 4.5/2.8
Pass band Flatness(dB)信道平坦度 0.3
Isolation(dB) Adjacent Channel 邻近信道 30
隔离度 Non-adjacent Channel 非邻近信道 45
Insertion Loss Temperature Sensitivity (dB/°C ) 插入损耗热稳定性 <0.005
Wavelength Temperature Shifting (nm/ °C ) 波长热稳定性 <0.002
PDL (dB) 偏振相关损耗 <0.10
PMD (ps) 偏振膜色散 <0.1
Directivity (dB) 方向性 >50
Return Loss (dB) 回波损耗 >45
Rated power (mW) 最大承载功率 500
Operation Temperature (°C) 工作温度 0 ~ +65
Storage Temperature (°C) 储存温度 -40 ~ +85
Dimension (mm) 尺寸 L100×W80×H10

Ordering Information

SCWDM
8=8 Channels
Channels Number 通道数 16=16 Channels
Application Type 应用类型 M=Mux
D=DeMux
510=1510nm
530=1530nm
Central Wavelength 中心波长 550=1550nm
570=1570nm
……
Fiber diameter 光纤直径 1=bare fiber
2=900um loose tube
Fiber Length 光纤长度 1=1 Meter
2=2 Meter
0=None
1=FC/APC
2=FC/PC
Connector 连接头 3=SC/APC
4=SC/PC
5=ST
6=LC
