Specifications
Payment Terms :
T/T; L/C; Paypal
Brand Name :
Sopto
Delivery Time :
3-5 working days
Certification :
ISO9001 / CE / RoHS
Model Number :
SPT-PDXX1G-XD
Date rate :
1.25Gbps
Fiber type :
SM
Distance :
80m to 120km
Operating temperature :
0 to 70℃
Interface :
LC
Description

Duplex LC Interface 1.25G DWDM SFP Module with DDM Commercial Temperature

SOPTO’s DWDM SFP is a series of optical transceiver modules operating at DWDM C-band (100GHz channel spacing) wavelengths over single-Mode Fiber (SMF). They are designed for use in Fast Ethernet, Gigabit Ethernet, 1G Fibre Channel, and SONET/SDH links, compliant with the SFP MSA. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell, etc.) compatible fiber optic transceivers.

Features

● RoHS-6 compliant

● Compliant with SFP MSA

● Compliant with FC-PI 13.0

● Compliant with IEEE Std 802.3

● Single +3.3V power supply

● Built-in digital diagnostic functions

● DWDM 100GHz ITU Grid C Band Available

● Transmission distance up to 120km over SMF

● Supports data rates from 100Mb/s to 1.25Gb/s

● Can be used with single fiber DWDM system or dual fiber DWDM system

● Operating Case Temperature: Standard: 0~70°C; Extended: -20~85°C; Industrial: -40~85°C

Applications

● Fast Ethernet

● Gigabit Ethernet

● 1X Fibre Channel

● SONET/SDH OC-3/STM-1

● SONET/SDH OC-12/STM-4

● SONET/SDH OC-24/STM-8

● DWDM Networks

Order Information

PN

Data Rate(Gbps)

 Distance Fiber

Output Power(dBm)

Sensitivity(dBm)

 Interface Temp.
SPT-PDXX1G-80D 1.25 80km SM 0～5 -24 Duplex LC 0 to 70℃
SPT-PDXX1G-120D 1.25 120km SM 0～5 -32 Duplex LC 0 to 70℃
