Specifications
Delivery Time :
3-5 working days
Brand Name :
Sopto
Certification :
CE,RoHS,ISO9001
Model Number :
SPT-PBX548-L(S)XXD
Packaging Details :
10 pcs/plate; 0.024kg/pcs
Payment Terms :
T/T; L/C; Paypal
Distance :
300m
Warranty :
life maintenance
Connector :
LC/SC
Application :
FTTH FTTB FTTX Network
Color :
Customized
Description

2.5G BIDI SFP Simplex SC or LC Interface with DDM Commercial Temperature

SOPTO’s 2.5G BIDI SFP is a series of optical transceiver modules designed for use in 2x/1x Fibre Channel and Gigabit Ethernet. They are operating at single-mode Fiber (SMF). They are compliant with the SFP MSA. Digital diagnostics functions are available. The optical transceivers are RoHS compliant. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell, etc.) compatible fiber optic transceivers.

Features

● Simplex SC or LC Interface

● Single +3.3V power supply

● Supports data rates up to 2.67Gb/s

● Built-in digital diagnostic functions

● Single Fiber BIDI SFP Optical Transceiver

● Transmission distance up to 120km over SMF

● Operating Case Temperature: Standard: 0~70°C; Extended: -20~85°C; Industrial: -40~85°C

Compliant

● RoHS-6

● SFP+ MSA

● FC-PI 13.0

● IEEE Std 802.3

Sopto fiber optic transceiver took the first lead to pass the ISO9001 quality system, the requirements of European CE, RoHS

Simplex Fiber SFP Module , 2.5G BIDI SFP Fiber Transceiver ISO9001 Certificate

Applications

● 2X/1X FC

● 1000Base Ethernet

● SDH/SONET

● Storage Area Network(SAN)

● Other Optical Link

Ordering Information

Products Data Rate(Gbps) Distance Fiber Output Power(dBm) Sensitivity (dBm) Interface Temp. DDM

SPT-PB3548-L(S)20D

SPT-PB5348-L(S)20D

 2.5 20km SM -9～-3 -24 Simplex LC/SC 0 to 70℃ D

SPT-PB4548-L(S)40D

SPT-PB5448-L(S)40D

 2.5 40km SM -3～0 -24 Simplex LC/SC 0 to 70℃ D

SPT-PB4548-L(S)60D

SPT-PB5448-L(S)60D

 2.5 60km SM -4～-1 -28 Simplex LC/SC 0 to 70℃ D

SPT-PB4548-L(S)80D

SPT-PB5448-L(S)80D

 2.5 80km SM -3～0 -28 Simplex LC/SC 0 to 70℃ D

SPT-PB4548-L(S)100D

SPT-PB5448-L(S)100D

 2.5 100km SM >0 -29 Simplex LC/SC 0 to 70℃ D

SPT-PB4548-L(S)120D

SPT-PB5448-L(S)120D

 2.5 120km SM >1 -30 Simplex LC/SC 0 to 70℃ D
