SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472
Specifications
Delivery Time :
3-5 working days
Brand Name :
Sopto
Certification :
ISO9001 / CE / RoHS
Model Number :
SPT-SFP28-XR
Payment Terms :
T/T; L/C; Paypal
Interface :
Duplex LC / MPO/MTP
Distance :
100m on MMF OM4 and 10km over SMF
Fiber type :
MMF
Wavelength :
850nm / 1310nm
Operating temperature :
Commercial 0 to 70℃
Description

25G SFP28 SR / LR Optical Transceivers 10KM over MMF with RoHS-6 compliant

SOPTO SFP28 optical transceivers are designed for use in 25GBASE data rate over multimode or single model fiber. The optical transceiver is compliant per the RoHS Directive 2011/65/EU.SFP28 is a 25GBASE interface which has evolved from 100 Gigabit Ethernet, which is typically implemented with 4 25 Gbit/s data lanes. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell etc.) compatible fiber optic transceivers.

Features

● RoHS-6 compliant

● Compliant with SFF-8472

● Built-in digital diagnostic functions

● Up to 25.78Gb/s bi-directional data links

● Operating Case Temperature: Standard: 0~70°C;

● Cost effective SFP28 solution, enables higher port densities and greater bandwidth

● Transmission distance up to 100m on MMF OM4 and 10km over SMF

● Advanced firmware allows customer system encryption information to be stored in transceiver

Sopto fiber optic transceiver took the first lead to pass the ISO9001 quality system,the requirements of European CE, RoHs

SR / LR Fiber Optic Transceiver 850nm / 1310nm Wavelength Compliant With SFF-8472

Applications

● 25GBASE-SR/LR Ethernet

● High-speed storage area networks

● Computer cluster cross-connect

● Custom high-speed data pipes

● Inter Rack Connection

Ordering Information

PN Data Rate(Gbps) Distance Fiber Output Power(dBm) Sensitivity(dBm) Interface Temp. DDM
SPT-SFP28-SR 25 70m/OM3
100m/OM4		 MM -8.4～2.4 -9.5 Duplex LC 0 to 70℃ D
SPT-SFP28-LR 25 10km MM -1.5～2 -13 MPO/MTP 0 to 70℃ D
