Specifications
Place of Origin :
Guangdong, China
Brand Name :
Sopto
Model Number :
SPWM-8MU-C47A1-LLU-2LR
Supply Ability :
10000 Unit/Units per Month
Packaging Details :
10 units per carton
MOQ :
10 - 99 Units
Price :
$524.00
Operating temperature(℃) :
-10 to +70
Warranty :
1~3 Years
Material :
1U(2U) Rackmount
Type :
Mux or Demux
Application :
FTTH FTTB FTTX Network
External size :
1U 19 inch
Adjacent Channel Isolation(dB) :
>=30
Return Loss(dB) :
>=45
Reflection Channel Isolation(dB) :
>=15
Non-Adjacent Isolation(dB) :
>=45
Port :
Shenzhen Port
Description

promotional price CWDM Mux/Demux 19 inch Rack with 2 LGX box G.657.A1 LC/UPC

Product Description

The CWDM Mux/Demux covers all channels from 1270nm to 1610nm in 20nm increments. It is a flexible network solution that allows network operators to cost effectively implement point to point or ring based WDM optical networks.

Mux/Demux can increase your network capacity combined with SOPTO Multiservice Transport Device (Such as EDFA, DCM, OEO and so on), which can improve the manageability and interconnectivity of WDM Network.

Features

>Low insertion loss

>Based on thin-film filter technology

>Multiplexing of up to 16/8 channels on fiber pair/single fiber

>Standard CWDM band 1470 nm - 1610 nm, 20 nm spacing

>Compliant to ITU-T G.694.2 standard and Telcordia GR1209, GR1221

>LC/SC/FC/ST, UPC/APC Interface are available

>Rate transparent for applications up to 10Gbps

>Monitor/Upgrade/1310nm Express port for external functions

>Completely passive, no electric power required

>Low-profile modular LGX box design optional, fits in LGX chassis

Applications

>CWDM Network

Specifications

Parameter

Unit

Specification

Operating Wavelength Range

nm

1260~ 1620

Center Wavelength

nm

Customer specified 4,8 or 16 wavelengths etc

Channel Spacing

nm

20

Pass band

nm

CW±6.5

Insertion Loss (With Connector)

dB

≤2.5

PDL

dB

≤0.2

Directivity

dB

≥50

Return Loss

dB

≥45

PMD

ps

≤0.1

Optical Power

mW

≤500

Operating Temperature

℃

-10 to +70

Storage Temperature

℃

-40 to +85

Fiber Type

G.657.A1 or G.652D

Interface Type

LC/UPC or others

Communication Type

Single or Dual Fiber

Optional functions

1310 Express port: 1310+/-40nm; Upgrade port: Unused wavelength section; Moniter port: 1%;

Note: The specific parameters are subject to the product specifications.

Ordering Information

Ordering Info. for CWDM MUX/DEMUX

Part Number:SPWM-8MU-C47A1-LLU-2LR

123 456 7 89 10 11 12 13
Product Description:CWDM Mux/Demux 19inch Rack with 2 LGX box of Dual fiber with Upgrade Port ,each 2× 8 wavelengths 1470-1610nm G.657.A1 LC/UPC

1 - Number of wavelengths

4:4 wavelengths; 8:8 wavelengths; 16:16 wavelengths; etc

2 - Type

M:CWDM Mux/Demux

3 - Optional functions

E:1310nm Express port; F:1550nm port; M:Moniter port; U:Upgrade Port

4 - Standard

C:Compatible with ITU-T G.694.2;

5 - First wavelength

27:1270nm; 29:1290nm; 31:1310nm; 33:1330nm; 35:1350nm; 37:1370nm; 39:1390nm; 41:1410nm; 43:1430nm; 45:1450nm; etc

6 - Communication Type

S:Single fiber; Null:Dual fiber;

7 - Fiber Type

D:G.652D; A1:G.657.A1;

8 - COM ports

L :LC; S:SC; F:FC;

9 - Other ports

L :LC; S:SC; F:FC;

10 - Endface

U :UPC polish; P :PC polish; A :APC polish

11- Package

L:LGX; R:19inch Rack Fixed; 2LR:19inch Rack with 2 LGX box;

12 - Height

Null:1U; 2:2U; 3:3U; etc

13 - Additional parameters

A31:Add 1310nm; S47:Skip 1470nm; etc
