Specifications
Brand Name :
LiangRu
Model Number :
Alloy PS45
Certification :
ISO9001:2005
Place of Origin :
China
MOQ :
200KG
Price :
To negotiate
Payment Terms :
T/T L/C
Supply Ability :
100000KG/MONTH
Delivery Time :
Short
Packaging Details :
Wooden Box, size as per guests request
Material :
Nickel Based
Welding Cost :
Low
Welding Durability :
High
Welding Efficiency :
High
Welding Penetration :
High
Welding Position :
Flat/Horizontal/Vertical
Welding Process :
MIG/MAG
Welding Quality :
Excellent
Welding Speed :
2.5m/min
Welding Strength :
High
Welding Temperature :
400-600℃
Wire Diameter :
1.6 Mm 2.0mm
Executive Standard :
AWS A5.14:2018,GB/T15620
Alloy Type :
Nickel-based Welding Wire
Other Name :
45CT，NICR44Ti，SNi6072
Description
Wear Resistant NICR Alloy PS45 NiCr44Ti Welding Wire 1.6mm 2.0mm AWS A5.14:2018

KX 45CT Sprayed Wire Welding Wire Light Rod on Nickel Based Welding Wire Alloy

Product Description and Application

45CT (PS45,NiCr44Ti)Sprayed Wire is used for fusion gas welding and tungsten inert gas welding, surfacing nickel-chromium alloy on Nickel iron chromium steel tubes and casting repair welding. The weld metal has the ability to resist high temperature corrosion and the smoke corrosion containing sulfur and alum in the air.

Process Performance and Requirements

  • Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

  • Product Chemical Composition
Grade C Mn Fe Si Cu Fe Ni Co Al Ti Cr
45CT Sprayed Wire 0.01-0.1 ≤0.20 ≤0.50 ≤0.20 ≤0.50 6.00～10.00 ≥52 ~ ~ 0.3-1.0 42-46

  • Other Technical Requirements

Welding Wire Diameter and Allowable Deviation

Package Welding Wire Diameter Allowable Deviation
Vertical Bar

1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2,

4.0,4.8,5.0,6.0,6.4

 ±0.1
Welding Wire Coil

+0.01

-0.04

Wire Reel

Diameter 100mm and 200mm

 0.8,0.9,1.0,1.2,1.4,1.6

Wire Reel

Diameter 270mm and 300mm

0.5,0.8,0.9,1.0,1.2,1.4,1.6,2.0,

2.4,2.5,2.8,3.0,3.2
Welding wire can be produced in other sizes, deviations and package as agreed by both parties
Allowable deviation of ±0.1 diameter when used for hand-filled wire

Welding Wire Loose Diameter and Warp Pitch

Diameter of Wire Reel 100 200 270,300
Loose Diameter 60~380 250~890 380~1300
Warp Pitch ≤13 ≤19 ≤25

  • Productive Process

  • Professional Customization

Cold-drawn Wire ¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire ¢5.5~¢20mm(Delivery in rolls)
Strip thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe ¢60~350mm,L800-2500mm
Hot-rolled Burnishing ¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing ¢2.5~18mm,L1000-8000mm
Seamless Tube ¢1~275mm,wall thickness 0.2~30,L1000-8000mm
