Ni Cr Fe N08800 Incoloy 800 Wire Nickel Alloy Wire 1,370°C Melting Point For Chemical Industry

Product Introduction

Incoloy 800 wire is an extremely important high-performance material in the chemical industry. Its excellent corrosion resistance enables it to remain stable in a variety of highly corrosive environments, especially in chlorides, low-concentration NaOH aqueous solutions, and high-temperature and high-pressure water, showing excellent resistance to stress corrosion cracking. The main components of this alloy include nickel, chromium, and iron, with a nickel content of about 30-45%, a chromium content of 15-25%, and a small amount of aluminum and titanium. The combination of these elements not only gives Incoloy 800 wire excellent corrosion resistance, but also ensures its stability and mechanical properties at high temperatures through solid solution treatment.
In the manufacture of chemical equipment, Incoloy 800 wire is widely used in the manufacture of reactors, heat exchangers, evaporators and other key components of the connection and support structure. These equipment need to operate for a long time in high temperature, high pressure and corrosive media. The high strength and corrosion resistance of Incoloy 800 wire ensure the reliability and safety of the equipment. In addition, Incoloy 800 wire also has good oxidation resistance and carburization resistance, and can work at high temperatures up to 1500°F (816°C).

Parameter

Specific Applications

1. Reactors and heat exchangers:Incoloy 800 wire is used to manufacture chemical reactors and heat exchangers, which need to operate for a long time in high temperature and corrosive environments. The corrosion resistance and high temperature strength of Incoloy 800 make it an ideal material, which can effectively extend the service life of the equipment and reduce the frequency of maintenance and replacement.
2. Coolers and cracking tubes:In chemical production, coolers and cracking tubes need to withstand the erosion of high temperature and corrosive media. Parts made of Incoloy 800 wire can effectively resist the corrosion of these media and ensure the long-term stable operation of the equipment.
3. Pipeline system:Incoloy 800 wire is used to manufacture chemical pipelines and their connectors. It can maintain good mechanical properties and corrosion resistance in highly acidic and high-pressure environments, ensuring the long-term stable operation of the pipeline system.
4. Pump shafts and valves:In the chemical production process, pump shafts and valves need to withstand the erosion of high temperature, high pressure and corrosive media. Parts made of Incoloy 800 wire can effectively resist the corrosion of these media and ensure the stability and reliability of the equipment.

Advantages and Characteristics

• Excellent corrosion resistance:Incoloy 800 wire performs well in a variety of corrosive media, including seawater, acid solutions, alkaline solutions, and hydrogen sulfide. A protective oxide film can be formed on its surface, effectively blocking the penetration of corrosive media.
• High strength and hardness:The tensile strength of Incoloy 800 wire is usually around 500 MPa and the yield strength is around 210 MPa. Its strength and hardness can be significantly improved through solution treatment and age hardening treatment.
• Good mechanical properties:Incoloy 800 wire maintains its mechanical stability in both low and high temperature environments and has good thermal and electrical conductivity. Its ductility and toughness greatly improve its safety in use under extreme conditions.

Contact Us

Email:fbwlau@cnrunlai.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service

Related Questions and Answers

What is Incoloy 800 Wire made of?

Incoloy 800 Wire is a nickel-based high-temperature alloy, mainly composed of nickel, chromium, iron and other elements, with excellent high-temperature strength and corrosion resistance.

What are the main application areas of Incoloy 800 Wire?

Incoloy 800 Wire is widely used in high-temperature and corrosive environments such as chemical, petroleum, aerospace, and nuclear industries, such as manufacturing electric heating elements, heat exchangers, reactors, etc.

What is the processing performance of Incoloy 800 Wire?

Incoloy 800 Wire has good cold processing performance and can be processed by turning, milling, grinding and other methods, but it is necessary to select appropriate tool materials and cutting parameters.

What is the heat treatment process of Incoloy 800 Wire?

The heat treatment process of Incoloy 800 Wire includes solution treatment (1144°C - 1698°C). Through proper heating and cooling, the grains of the alloy can be fine and uniform, thereby improving its mechanical properties and heat resistance.
