Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data
Specifications
Brand Name :
JINSP
Model Number :
SR50R
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100 PCS/70-90 days
Delivery Time :
30-50working days
Packaging Details :
Customized Packaging
Effective pixels :
128 (256 optional)
Cell size :
50μm*250μm
Sensitive area :
6.4mm*0.25mm
Data Output Interface :
USB2.0, UART
Wavelength Accuracy :
±0.3 nm
Measurement Range :
900-1700 nm
Spectral Resolution :
0.1 nm
Integration Time :
1 ms - 10 s
Description

High-Performance Near-infrared Fiber Modular Spectrometer

The JINSP SR50R17 spectrometer offers a compact and cost-effective approach to near-infrared spectroscopy, covering the 900nm to 1700nm range. It includes a non-cooled InGaAs sensor that provides high sensitivity and resolution. Equipped with a matching light source, optical fiber, and testing rack, this device is highly suitable for near-infrared absorption, reflection, and transmission measurements to analyze the optical properties of materials, including absorption, scattering, and transmission, and evaluate the quality and performance of materials. Its competitive price also makes it an ideal choice for industrial NIR spectrometer system integration.

Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data

Features

  • The unit's small size and light weight make it highly portable and simple to manage.
  • The gold-coated lens offers superior near-infrared reflectance, ensuring precise and reliable performance.
  • It is designed to work with USB or UART for spectral data output, facilitating seamless integration into a variety of systems and devices.

Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data

Technical Parameters

Product Name Near Infrared Non-cooled Spectrometer
Wavelength Range 900-1700nm
Chip Type Linear array InGaAs
Entrance Slit width 5μm, 10μm, 25μm, 50μm (customizable)
Incident Light interface SMA905, free space
Integration Time 1ms-5s
Operating Humidity <90%RH (no condensation)
Dimensions 77mm*67mm*36mm
Weight 0.4KG

Applications

  • Moisture content measurement, waste water testing
  • Detection of substances such as fat, oil, protein, fiber etc.
  • Grain and fodder quality testing
  • Measurement ofpharmaceutical mixturecomponents
Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data

Support and Services

The Near infrared spectrometer provides high-performance spectral measurements in a portable and affordable package. Our product technical support and services include:

- Expert technical assistance and troubleshooting

- Comprehensive product documentation and user manuals

- Software updates and upgrades

Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data

Company Profile and Exhibition

JINSP Company Limited originates from Tsinghua University and has 17 years of experience in developing spectroscopic technology.As a leading supplier of spectroscopic technology, JINSP Technology offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, customs, and fiber optic spectrometers. Our products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.

Modular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral DataModular Near-infrared Fiber Spectrometer Supports USB And UART For Exporting Spectral Data

FAQ

Q1:This is the first time I use,is it easy to operate?

A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.

Also our technicians will offer professional tecnical opearation meetings.

Q2:Can you offer a operation training?

A2:Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local

support( installation , training, debugging, maintenance ).

Q3:How to receive a best price in the shortest time?

A3:When you send us an inquiry,please kindly offer details with wavelength,detector,effective pixels,focal length

and so on.We will send you quotation with details soon to your email.

Q4:If the spectrometer has problem in my place,how could I do?

A4:The spectrometer has one year warranty.If it breaks down,our technician will figure out what the problem maybe,

according to client's feedback.We can repair for free within one year warranty.

Q5:Which payment can be acceptable ?

A5:We could accept the payment by T/T, Paypal, Western Union,L/C, etc.
