22 Groups Infrared Beam Airport Turnstile With Rs485 Communication Interface
22 Groups Infrared Beam Airport Turnstile With Rs485 Communication Interface
Specifications
Brand Name :
DOOR
Model Number :
DR.TD.6631
Certification :
CE / IS09001
Place of Origin :
China
MOQ :
1 lane
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
2500 sets per month
Delivery Time :
5-7 working days
Packaging Details :
wood carton
Motor :
Servo motor
Material :
304# stainless steel
Size :
L1516×W200×H1511.31mm
Power supply :
AC110V/AC220V±10% 50-60Hz
Channel Width :
≤700mm
Working environment :
Indoor
Color :
Silver
Communication interface :
RS485,dry contact
Description

22 groups Infrared beam airport turnstile with RS485 Communication Interface

Device Parameter:

  • Structure Parameter

  1. Material: SUS304 brushed stainless steel,

  2. top cover 2.0mm, whole body 1.5mm, Acrylic Arm

  3. Size: L1516×W200×H1511.31mm

  • Technical Parameter
Passage Width
SUS304 brushed stainless steel
Top cover 2.0mm, whole body 1.5mm
Passing Speed
30-35personal/min
Opening Speed
Adjustable, fastest 0.5s
Working Temperature
-25℃-+70℃
Mean Cycles Between Failure
5 million times
IP Rating IP42
  • Electric Parameter
1.Voltage: AC110V/AC220V±10% 50-60Hz
2.Driving Motor: Servo motor
3.Method of Position: motor driving
4.Communication Interface: RS485
5.Input Signal: dry contact signal
6.Number of Sensor: 22 groups

FAQ:

Q1: Do you have English version system?

A: Yes, we can provide English version system. Also you can use your own system as well.

Q2: Does the equipement include control board?

A: Yes, it is with control board. But if need our system to management, need to order extra channel management control board.

Q3: Can we connect your access control system with our system?

A: Yes, we provide SDK and Software development service with connection port.

Q4: How can we install the turnstiles/barrier gates? Is it easy?
A:Yes, it's easy to install, we have done most of the jobs before sending our products. You just need fix the gates with screws, and connect power supply cables and internet cables.Also we provide one sheet of specific manual specification in the package.

Q5: What is your company’s strength?

A: We are the top 3 manufacturer in turnstile field in China. And we are listed company with famous brand in China. We have more than 400 employees, a R&D group with 160 people, 15-person customized team, 18 offices, 9 agents and more than 20 distributors all around China.

Q6: How do you do after-sale service?

A: We provide life-time technology support on line, by emails, video, phone etc. We have engineer speaking English, convenient to communicate with you directly.

Q7. How about the lead time?

Normally we have raw material in stock for the hot sale models of standard products. Regular products need 5-7 working days. The customized products need 15-20 working days.

Certification:

Factory Show:

Company Introduction:

Shenzhen Door Intelligent Control Technology Co.,Ltd. (Stock Code 832966) is a high-tech
enterprise in the field of intelligent access control based on cloud computing, which located in
Longhua District, Shenzhen. The company has more than 400 employees, including 200 R&D
and technical personnel. Door has already achieved National High-Tech Enterprise Certification,
Double Soft Enterprise Certification, ISO9000 International Quality System Certification and
CE Certification. Meantime, the company has obtained over 60 invention patents and national
software copyright with registered capital of CNY 100.06 million.
