Audio Stainless Steel Mesh Cylinder , Optional Thickness Perforated Stainless Pipe
Audio Stainless Steel Mesh Cylinder , Optional Thickness Perforated Stainless Pipe
Specifications
Brand Name :
Forward
Model Number :
SSMT
Certification :
ISO9001
Place of Origin :
China
MOQ :
100 pieces
Price :
USD+ 20-50 + Pieces
Payment Terms :
T/T, L/C
Supply Ability :
100000+Pieces+Month
Delivery Time :
10 working days
Packaging Details :
Wood Carton
Material :
Stainless Steel
Application :
Audio
Thickness :
Optional
Package :
Wood Carton
Advantage :
Durable
Product Name :
Stainless Steel Mesh Cylinder
Description

Audio Stainless Steel Mesh Cylinder , Optional Thickness Perforated Stainless Pipe

Stainless Steel mesh tube filter is made by stainless wire cloth, and perforated metal roll. Those materials are can be customized, but most of them have certain size like wire cloth is from 2 mesh to 500 mesh and perforated roll is from 1mm diameter to 30mm diameter, with less thickness than diameter.

Stainless Steel Mesh Tube Filter is part of filtration, it can be used in many applications like filter supporter, water filtration, oil filtration, strainer tubing,

The specification is normally as follows

Sheet Thickness Opening in Width Opening in Length Stem Roll Width Roll Length Weight
(mm) mm mm mm kg/m
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35
8 50 100 8 2 2.1 28.26
Actually not only stainless steel, but also other alloy like aliumium, copper, monel can also be required.
