Specifications
Brand Name :
Sincere
Model Number :
SMPC-63,SMPC-50,SMPC-110
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
7-15 work days
Machine Weight :
1500kg
Material :
Plastic
Max. Diameter :
50mm
Machine Dimension :
5000*1000*1500mm
Extrusion Speed :
10-50m/min
Cooling Method :
Water Cooling
Max. Output :
100kg/h
Control System :
PLC
Heating Power :
7kw
Motor Power :
11kw
Power Supply :
380V/50Hz
Operating Interface :
Touch Screen
Extrusion Type :
Single Screw
Description

PVC TPU Layflat Hose PVC Fiber Reinforced Soft Hose ProductionLine
PVC High-Strength Coated Water Layflat irrigation Hose Production Line

1. PVC TPU Layflat Hose Applacations:

PVC special high-strength coated water production line is my company absorb and digest foreign advanced technology and self-developed new products, it produces polyester fiber as a reinforcing material, by a special process and extruded plastic extruded PVC material forming Of the hose. The hose produced by the production line has the advantages of good flexibility, high pressure resistance, corrosion resistance, aging resistance, light weight and infinite length.
PVC Garden Irrigation Hose Making Production Line PVC Braiding Layflat Hose Extrusion Machine


2.Materials:

100% virgin PVC materials,Non-toxic,Non smell.High tensile polyester yarn.Good quality material make light weight,good flexibility,easy handling. Soft and flexible. Anti abrasion,Anti-corrosion,Anti-aging.

3.TPU / PVC fire/ water hose/ tube/ pipe extrusion production equipment configuration:
single screw inner extrusion system, cooling device, haull-off machine, package yarn machine, single screw outer extrusion system, cooling device, automatic winding system. To achieve a high-speed extrusion and winding uniform work, can configure the corresponding mold can also produce a variety of specifications of the soft shaped pipe/ hose.

4.Technical Parameters

ModelScrew diameter
(mm)		LDScrew and Barrel MaterialExtruder Motor
(kw)		Center hight
(mm)		Hose diameter range
(mm)
SJ-555530 or 2838CrMoAlA1111001''-2''
SJ-757530 or 2838CrMoAlA18.511002.5''-4''
SJ-909030 or 2838CrMoAlA3711004''-6''
SJ-12012030 or 2838CrMoAlA5511006''-8''





British MeasurementMetric MeasurementW.P.B.P.WeightMaximum elongation at W.P.Maximum diameter swell at W.P.
I.D.ToleranceLength
inchmmmmmMpaMpakg/roll%%
125-0/+11008251516
1-1/432-0/+11008251716
1-1/238-0/+11008252016
250-0/+11007202816
50-0/+11005162016
2-1/264-0/+11005163816
64-0/+11003112716
375-0/+11003114616
75-0/+11003113516
3-1/290-0/+11003115516
4102-0/+11003116216
5127-0/+11003117116
6152-0/+11003118516
8200-0/+110031116016
