Specifications
Place of Origin :
Guangdong, China
Brand Name :
HYYX
Model Number :
HYW-1275-090
Supply Ability :
10000 Piece/Pieces per Week
Packaging Details :
1. Inside + outside strong double boxes 2. Customized
MOQ :
2 Piece/Pieces
Price :
$50.00 - $77.00 / Piece
Product Name :
12 inch neodymium speaker
Sensitivity(1w/1m) :
98dB
Frequency Response :
50Hz-4.5KHz
Nominal Impedance :
8 ohm
Size :
6.5/8/10/12/15/18/21Inch Optional
Rated Power :
450W
Max power :
900W
Paper material :
Carbon cone
Magnet material :
Neodymium
Voice coil diameter :
75mm / 3 inch
Port :
Huangpu, Nansha
Description
Product Description
12 inch neodymium speaker midbass speaker with carbon cone for line array speaker 98dB

This 12 inch Neodymium woofer Speakers offers outstanding efficiency , high sensitivity 98dB. Its very high power handling(450W RMS ) and Xmax capabilities make it suitable for any pro audio speaker enclosure, including LINE ARRAY SPEAKER SYSTEM.

Specification


Features :

- 12 inch midbass speaker with neodymium magnet and carbon cone
- 1800W continuous program power capacity / 450W RMS
- 98dB sensitivity 1W/1M
- 50hz-4.5khz Frequency response
- Neodymium magnet
- 3 inch/75mm copper voice coil
- Carbon cone and dust cap to give higher efficiency
Speccification :
Specification
Nominal diameter
300/12
mm/inch
Nominal impedance
8
ohm
Min impedance
5.2
ohm
Frequency response
50-4.5k
Hz
Magnet material
Neodymium
Sensitivity (1w/1m)
98
dB
RMS power handling
450
Watts
Continuous power handling
1800
Watts
Voice coil diameter
75/3
mm/ inch
Winding material
Copper
Cone material
Carbon
Surround material
Cloth
T/S Parameter
Fs
52.6
Hz
Re
5.2
Ω
Qes
0.45
Qts
0.44
Qms
13.45
Vas
49.7
L
Rms
1.8
kg/s
Cms
0.13
mm/N
Mms
72.8
gr
BI
16.6
N/A
Rp
86.9
Ω
Lp
40.5
mH
Cp
438.4
uF
Le
0.6
mH
Xmax
7
mm
Mounting information
Overall diameter
312/12.3
mm/inch
Bolt Circle diameter
295/11.6
mm/inch
Baffle Cutout diameter
279/11
mm/inch
Depth
145/5.6
mm/inch
Flange thickness
13/0.51
mm/inch
Shipping information
Net weight
3.8
KG
Shipping weight
4.5
KG
Shipping box
340x340x170
mm
