CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
Specifications
Place of Origin :
Guangdong, China
Brand Name :
HYYX
Model Number :
HYW-12100-001
Supply Ability :
5000 Piece/Pieces per Week
Packaging Details :
1. Plastic bags + Inner box + master carton 2. The boxes could be customized with logo
MOQ :
10 Piece/Pieces
Price :
$30.00 - $50.00 / Piece
Product Name :
12 inch woofer speaker
Frequency Response :
45Hz-3.5KHz
Sensitivity :
98dB
Nominal Impedance :
8 Ohms
Size :
12 inch
Rated Power :
600W
Voice coil material :
CCAW/Copper
Voice coil diameter :
4 inch / 100mm
Magnet material :
Ferrite
Magnet size :
220x25mm
Port :
Huangpu, Nansha
Description

12 inch big power midbass speaker pro audio speaker 600WRMS woofer speaker 12 inch

Product Description


Features :

- Professional 12 inch woofer/Midbass speakers

- 600W RMS power handling

- 98dB sensitivity (1w/1m)
- 45hz-3.5khz frequency response
- 4" High temperature CCAW voice coil wire and fiberglass former
Specification
Nominal diameter
300/12
mm/inch
Nominal impedance
8
ohm
Min impedance LF
5.2
ohm
Frequency response
45-3.5k
Hz
Magnet size
220x25
mm
Magnet material
Ferrite
Sensitivity (1w/1m)
98±3
dB
Nominal power handling
600
Watts
Continuous power handling
1200
Watts
Voice coil diameter
100/4
mm/ inch
Winding material
CCAW / Copper
Cone material
Paper
Surround material
Cloth
T/S Parameter
Fs
66.5
Hz
Re
5.2
Ω
Qes
0.58
Qts
0.56
Qms
15.19
Vas
21.4
L
Rms
3.0
kg/s
Cms
0.05
mm/N
Mms
108.6
gr
BI
20.2
N/A
Rp
103.0
Ω
Lp
20.8
mH
Cp
546.7
uF
Le
1.0
mH
Xmax (one-way)
9
mm
Mounting information
Overall diameter
312/12.28
mm/inch
Bolt Circle diameter
295/11.6
mm/inch
Baffle Cutout diameter
279/10.98
mm/inch
Total Depth
139/5.5
mm/inch
Flange thickness
12/0.47
mm/inch
Shipping information
Net weight
10.28
KG
Shipping weight
11.5
KG
Shipping box
330X330X170
mm

CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker

Our Company

Company Profile

Since our establishment in 2009, we have been committed to manufacturing high-quality audio products, including professional audio speakers, car audio speakers, speakers with cabinets and power amplifiers. Since then, Huiyin Audio Co., Ltd. has had a complete high-quality supply chain, an excellent management team, and the ability to provide our customers with good service and high-quality products at a good price! Instead, the company introduced a series of advanced equipment such as automated production lines, high-efficiency magnetizers, impact testing machines, and temperature testing machines. To maximize, we obtained CE certification in 2012. The enterprise will be gradually developed in 2017.

We are willing to customize the speakers and amplifiers required by customers to suit their market. OEM and ODM orders are welcome.
Committed to strict quality control and thoughtful customer service, our experienced staff are always available to discuss your requirements and ensure complete customer satisfaction. When we cooperate with well-known Chinese brands, our products are also exported to customers in North America, South America, Europe, Asia, Africa and Africa and Oceania and other countries and regions. Whether it is selecting the current product from our catalog or seeking the help of an engineer to manufacture other ideal speaker models, please contact our customer service center or send an email to us. We want to establish a long-term business relationship with you.

CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
Packing & Delivery
CCAW Voice Coil 3.5khz 600 Watt 12 Inch Midbass Speaker
FAQ

1.Q: Are you a factory ?
A: Yes, We are professional manufacturer who focus on quality speakers.

2.Q: What's your products range?

A: Pro audio speaker, amplifier, car audio speaker and home audio speaker .

3.Q: Can I get some samples?
A: Yes, we could provide samples and ship samples by DHL, EMS, FedEx or by sea .

4.Q: What's the payment method ?
A: T/T , Western union and PayPal.

5.Q: Can you print our logo on the speaker and packing?
A: Yes , we would like to do it for your OEM orders .

6.Q: Could you build speakers based on customer's design ?
A: Yes , customized order is welcome .

7.Q: Do you accept small order ?
A: Yes, small quantity order is accepted because we have most speakers in stock for this kind of trade.
