Specifications
Brand Name :
Shinhom
Model Number :
LAN-100
Place of Origin :
China
Certification :
RoHS
MOQ :
5000PCS
Packaging Details :
Carton
Delivery Time :
4~8 Weeks
Payment Terms :
T/T
Supply Ability :
1000000/MONTH
Price :
Negotiation
Name :
SMT LAN transformer
Range of Application :
Choke
Transport Package :
Tape & Reel
Feature :
Fire/Flame Retardant
Specification :
10/100base-t single port
Operating Temperature :
0 ~ 70℃
Description

LAN-100 Seires 10/100Base-T Magnetics modules,Power/Circuit SMD Ethernet Single Port Lan Magnetic Transformer

FEATURES:

· IEEE 802.3,ANSI X3.263
· SMT & Thru Hole available
· Miniature size

· Primary OCL Tx & Rx: 350μH Min @ Idc=8mA
· Hipot : 1500 VRMS

· Soldering methods:Wave,Reflow
· Operating Temperature:0℃ to 70℃
· Storage Temperature:-55℃ to 125℃

Magnetic Ethernet LAN Transformer , Ethernet Isolation Transformer LAN
