Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Avoid Crosstalk SMD Motherboard Inductor For High Density Installation
Specifications
Brand Name :
Shinhom
Model Number :
AIML0805 Series
Certification :
RoHS
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000000/MONTH
Delivery Time :
4~8 Weeks
Packaging Details :
Carton
Installation :
SMT
Size :
2.0*1.25*0.8mm
Application :
CD-ROM, Hard Disk, Modem, Printers
Inductance :
47nH to 82uH
Type :
Chip inductor
Current range :
5mA-300mA
Description

AIML0805 Series chip inductors,Multilayer Chip Inductor,Ferrite Beads Motherboard Inductor,SMD inductor

Features:

  1. Avoids crosstalk
  2. High reliability
  3. Excellent solderability
  4. Closed magnetic circuit
  5. Closed magnetic circuit avoids crosstalk
  6. Sizes 0402 / 0603 / 0805 / 1206 / 1210
  7. Suitable for high density installation and re-flow soldering
  8. Counter measures for complying with FCC,VDE,CSA,VCCI and CE

Applcations:

  1. CD-ROM, Hard Disk, Modem, Printers
  2. Printer Equipment
  3. Portable Equipment
  4. DSC, DVC, PDA, DVD and HDD
  5. Medical Equipment
  6. Testing/Measurement Equipment
  7. Converters
  8. Automatic Equipment Controller
  9. Communication Device, Cell phone ,GPS ,PDA
  10. Personal Computers

Technical information:

  1. Testing:(Equivalents acceptable) lnductance & Q-HP4195A+HP41951
  2. electrode shall be covered Preheat:@ 180℃±5℃ for 2-3 minutes Solder temperature:230℃for 4 seconds ±1 second Flux:Emersion into methanol solution with Colophony for 3 to 5 seconds.
  3. IDC:The DC current at which tither the initial L value is decreased by 5% with the application of DC bias or the value of current at which the temperature of the element is increased by 20℃
  4. Operating Temperature:-40℃ to +100℃

Avoid Crosstalk SMD Motherboard Inductor For High Density Installation

Notes: Product size and inductance can be customized
