Specifications
Brand Name :
Shinhom
Model Number :
AT2510P
Certification :
ISO9001-2000, UL, ISO9001, CCC, CE
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000000/MONTH
Delivery Time :
4~8 Weeks
Packaging Details :
Carton
Frequency :
50/60Hz
Application :
Audio output transformer
Insulation :
UL Insulation System for Class B (130), F (155), H (180)
Product name :
Low frequency Transformer
Operating temperature :
-25℃to+125℃
Description

Microphone Split Transformer , AF Transformer

Features:

• Provides 2 additional, isolated balanced outputs as mic 'splitter'
• Stops 'ground loop' problems when a mic feeds multiple preamps
• High common-mode rejection: 130 dB at 60 Hz
• Excellent frequency response and time domain performance
• Low insertion loss: 1.2 dB

Application:

This transformer is designed for drive from a 150 Ω microphone source and for each secondary to be loaded by the 1 kΩ input impedance typical of microphone preamplifiers. A pair can be used to make a passive matrix when using the M-S stereo microphone technique. A 30 dB magnetic shield

Electrical specification:

  • Inductance: 12-11: 3.0H±20%@1KHz,0.3V
  • 5-4: 3.0H±20%@1KHz,0.3V
  • 8-7: 3.0H±20%@1KHz,0.3V
  • DCR: 12-11: 50Ω±15%
  • 5-4: 51Ω±15%
  • 8-7: 58Ω±15%
  • Hi-Pot: 500Vac,5mA,1S Pri to Sec
