Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v
Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v
Specifications
Brand Name :
CNP NM FIRE
Model Number :
SCF150-125-250
Certification :
UL Listed
Place of Origin :
China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, T/T
Delivery Time :
60 Days
Packaging Details :
Export Packing
CAPACITY :
1000GPM
HEAD :
120PSI
Driving Mode :
MOTOR DRIVER
Controller :
Tornatech (UL/FM)
Frequncy :
50HZ
Voltage :
400V
Description
  • UL Split casing Pump Pump , MOTOR DRIVER Fire Pump 1000gpm@119psi
  • Product Details

Motor Pump Set
NM Fire Split Case Pump
ModelSCF150-125-250 (UL) This Electric pump Set includes the pump(air relieve vlave , inlet & outlet gauges) , Motor, Control System,Commonbase.
Capacity 1000GPM
Head 119PSI
RPM 2980rpm
Material: 　
Casing Ductile Cast iron
Impeller SS304
Shaft AISI 4340
Shaft sleeve SS304
Seal Gland packing
Wear ring Bronze
Bearing SKF
Engine: TECHTOP&UL
Model: TDC 405TS150U2B
Controller : Eaton(UL/FM)
Model: FD70-150J-L1

The above models are used for 1000GPM@119PSI MOTOR DRIVER 50HZ 400V.

Please contact us if you have any other requirements.

Thanks

  • CERTIFICATE

Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v

Standards

NFPA20, UL, FM, EN12845,CCCF

Performance Ranges

UL : Q: 100-750GPM H:70-152PSI

FM: Q: 100-750GPM H:70-152PSI

CCCF: Q:15-45L/S H:0.6-0.9Mpa

NFPA20: Q: 100-3000GPM H:40-200PSI

  • Application:

Industrial fields: All petroleum, petrochemical, chemical, oil fields, pipelines bureaus, oil repositories, oil terminals, oil refineries, offshore platforms, etc.; National grain storages, thermal power plants, steel plants, shipyards, paper mills, etc.;
Commercial Field: five-star hotels, hospitals, schools, supermarkets, office buildings, large-scale commercial complex, highway tunnels, subway stations, railway stations, airports; Fire-fighting Engineering Companies;

Please note :the pump will be not sold individual,it must be match with engine or electric motor driver.

  • History of CNP and NM Fire:

Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v

CNP was founded more than 25 years,At the beginning, CNP focused on the research and development of stamping and welding stainless steel centrifugal pumps.

Now CNP is the second largest manufacturer on the stainless steel centrifugal pump in the world.

CNP Headquarter :300,000 m2

Over 30 Subsidiaries

More than 5000 staffs

The subsidiary corporations is as follows:
Manufacturing
Environmental protection
•NANFANG PUMP INDUSTRY CO., LTD.
•HANGZHOU NANBENG ENERGY-SAVING TECHNOLOGY Co. Ltd
•HUZHOU NANFENG MACHINARY MANUFACTURING Co. Ltd
•CNP CHANGSHA Co., Ltd.
•CNP NM FIRE FIGHTING SYSTEM CO.,LTD
•HANGZHOU CNP-TSURUMI PUMP CO.,LTD
•HANGZHOU HOWELL FLOW Co., Ltd.
•NANFANG INDUSTRY PTE. LTD.
•TIGERFLOW SYSTEM LLC
•JINSHAN ENVIROMENTPROTECTION SCIENCE and TECHNOLOGY CO.,LTD
•BEIJING ZHONGZIHUAYU ENVIRONMENTAL TECHNOLOGY CO.,LTD

CNP and NM Fire set up a cooperative enterprise in October,2013. introducing some experienced talents with international first-class technical level. The designation and production of the products are strictly consistent with requirements of international certificates,for changing the backward conditions in domestic market.

  • NMFIRE 2018 International Training Conference

Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400vMotor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400vMotor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v

Split casing Pump Model Chart

​

Rated Capacity Model
Designation		 Rated Net Pressure Range, Approx. Speed, Maximum Working Pressure, Impeller Diameter, mm.
GPM (US) PSI RPM PSI Max Min
300 SCF125-100-300 123-195 2980 400 315 250
400 SCF125-100-300 120-189 2980 400 315 250
400 SCF125-100-300 173-274 3550 400 315 250
450 SCF125-100-300 119-187 2980 400 315 250
450 SCF125-100-300 172-272 3550 400 315 250
500 SCF125-100-300 117-184 2980 400 315 260
500 SCF125-100-300 170-269 3550 400 315 260
750 SCF125-100-300 104-163 2980 400 315 260
750 SCF125-100-300 157-247 3550 400 315 260
750 SCF125-80-350G 169-251 2980 261 330 280
750 SCF150-100-320 138-198 2980 202 300 255
1000 SCF150-100-320 130-191 2980 202 300 240
1000 SCF200-150-310 119-237 2980 350 335 240
1000 SCF200-150-310 175-253 3550 350 290 240
1250 SCF200-125-300 116-190 2980 187 300 240
1250 SCF200-125-380 118-177 2200 261 385 325
1250 SCF200-150-310 112-230 2980 350 335 240
1250 SCF200-150-310 168-247 3550 350 290 240
1500 SCF200-150-310 158-236 3550 350 290 240
1500 SCF200-150-460 115-181 1800 275 460 380
2000 SCF200-150-460 118-175 1800 275 460 395
2000 SCF250-200-350 123-239 2980 362 360 260
2500 SCF250-200-350 114-227 2980 362 360 260
2500 SCF250-200-430 138 1800 275 425 n/a
2500 SCF250-200-430 125-190 2100 275 425 360
3000 SCF250-200-430 144-187 2100 275 425 390
3500 SCF300-250-490 119-189 1800 290 490 410
4000 SCF300-250-490 114-185 1800 290 490 410
4500 SCF300-250-490 153-181 1800 290 490 460
4500 SCF400-350-640 129-196 1480 315 655 540
5000 SCF400-350-640 127-194 1480 315 655 540
5500 SCF400-350-640 124-192 1480 315 655 540
6000 SCF400-350-640 120-190 1480 315 655 540
6500 SCF400-350-640 116-186 1480 315 655 540
7000 SCF400-350-640 113-182 1480 315 655 540
7500 SCF400-350-640 109-179 1480 315 655 540
 ​ ①The late-mover advantage of products, we R&D better fire products than other Suppliers;  ②Have the most complete and all series of fire pump models;  ③Have listed diesel engines with self-owned brand--- NM FIRE；  ④Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services；  ⑤Shorter delivery time.

Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v

 Q1.Do you have the UL-LISTED Fire Pump Sets?  Yes, We have the UL/FM and NFPA standard Fire Pump Sets.  Q2.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ?  Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together.  Q3.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ?  You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together.  Q4.I need the UL/FM Vertical Tubine Fire Pump Set ,please sent me the price.  For the motor Diver Vertical Tubine Fire Pump Set: you shoul give us the Capacity, Heed, Voltage Frequncy and the tank deep.  For the Diesel Engine Drive Vertical Tubine Fire Pump Set:you should give us the Capacity, Heed and the tank deep.  If you need Jockey Pump or other accessories,please tell us together.

 1. Reply within 24 hours. 2. High-quality products and the most reasonable price 3. Data and chemical technology support.

  • Five Advantages of CNP NM FIRE

    • FAQ

    • Service:

Motor Driver Split Case Fire Pump Set With SS 304 Impeller 50hz-400v
